Printers & POSZyxel GS1005HP - switch - 5 ports - unmanaged
SKU GS1005HP-EU0101F
| Product Description: | Zyxel GS1005HP - switch - 5 ports - unmanaged |
| Device Type: | Switch - 5 ports - unmanaged |
| Subtype: | Gigabit Ethernet |
| Ports: | 4 x 10/100/1000 (PoE+) + 1 x 10/100/1000 |
| Power Over Ethernet (PoE): | PoE |
| PoE Budget: | 60 W |
| Performance: | Switching capacity: 10 Gbps |
- Specifications
- Description
| General | |
| Device Type: | Switch - 5 ports - unmanaged |
| Enclosure Type: | Desktop, wall-mountable |
| Subtype: | Gigabit Ethernet |
| Ports: | 4 x 10/100/1000 (PoE+) + 1 x 10/100/1000 |
| Power Over Ethernet (PoE): | PoE |
| PoE Budget: | 60 W |
| Performance: | Switching capacity: 10 Gbps |
| MAC Address Table Size: | 2K entries |
| Jumbo Frame Support: | 9KB |
| Features: | Flow control, full duplex capability, auto-negotiation, auto-uplink (auto MDI/MDI-X), store and forward, QoS, fanless, 128KB packet buffer, loop prevention, EEE |
| Compliant Standards: | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3az |
| Status Indicators: | Power, PoE, link/activity |
| Expansion / Connectivity | |
| Interfaces: | 4 x 1000Base-T RJ-45 PoE+ - 30 W ¦ 1 x 1000Base-T RJ-45 |
| Power | |
| Power Device: | External power adapter |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational: | 72 Watt |
| Miscellaneous | |
| Included Accessories: | Rubber pad |
| Compliant Standards: | BSMI, EMC, FCC, LVD |
| Localisation: | Europe |
| Dimensions & Weight | |
| Width: | 12.1 cm |
| Depth: | 7.5 cm |
| Height: | 2.6 cm |
| Weight: | 235 g |
| Dimensions & Weight (Shipping) | |
| Shipping Width: | 21 cm |
| Shipping Depth: | 13.2 cm |
| Shipping Height: | 7.8 cm |
| Shipping Weight: | 834 g |
| Environmental Parameters | |
| Min Operating Temperature: | 0 °C |
| Max Operating Temperature: | 40 °C |
| Humidity Range Operating: | 10 - 90% (non-condensing) |
| Min Storage Temperature: | -40 °C |
| Max Storage Temperature: | 70 °C |
| Humidity Range Storage: | 10 - 90% (non-condensing) |
The Zyxel GS1005HP Gigabit Unmanaged PoE Switch is equipped with 5 Gigabit Ethernet ports, 4 of which are PoE ports that can deliver up to 60 w of total PoE budget. The GS1005HP can easily connect with PoE ready devices to your network with plug-and-play design and provides power-saving benefits without compromising performance. The GS1005HP fills a long-standing hole in the market for unmanaged PoE switches that feature the 802.3at standard, have a high power budget and are affordable for SOHOs and small businesses.
- 5-port PoE/PoE+ gigabit switch with a 60w power budget
- Features 4 ports that support industry standard 802.3af and 802.3at PoE and PoE+ Up to 30 watts per port (60 watt total budget)
- Perfect for small offices, compatible with IP Cameras, IP Phones, Wireless Access Points and other PoE devices
- Fanless design for silent operation without the noise of some other PoE solutions
- Rugged metal design can handle the toughest environments, can be mounted on a wall or desktop
- Unmanaged switch offering true plug and play installation and use. No GUI or installation software
The technical details come from 3rd party. edgemo is not responsible for any errors.
