Symbol LS2208 - barcode scanner

SKU LS2208-SR20007R-KR
Product Description:Symbol LS2208 - barcode scanner
Type:Barcode scanner - handheld - keyboard wedge - decoded
Colour:Twilight black
Minimum Bar Width:5 mil
Scan Element Type:Visible laser diode
Scan Speed:100 scan / sec
Connectivity Technology:Wired
In Stock(24)
  • Specifications
  • Description
General
Type:Barcode scanner - handheld
Colour:Twilight black
Barcode
Interface Type:Keyboard wedge
Minimum Bar Width:5 mil
Scan Element Type:Visible laser diode
Light Source Wave Length:650 nm
Scan Mode:Single-pass
Scan Speed:100 scan / sec
Skew (Degrees):60
Pitch (Degrees):65
Print Contrast Signal (PCS):20%
Decode Capability:Code 93, Code 39, UCC/EAN-128, IATA, GS1 DataBar, Discrete 2 of 5, Codabar, Code 128, Code 11, UPC, Interleaved 2 of 5, MSI-Plessey
TTL Decoding:Decoded
Connectivity Technology:Wired
OK Notification:Beeper, LED indicator
Features:Triggered, Advanced Data Formatting (ADF)
Expansion / Connectivity
Interfaces:1 x keyboard wedge
Miscellaneous
Included Accessories:Stand
Cables Included:1 x keyboard wedge cable
Compliant Standards:VCCI, EN 60950, IEC 950, UL 1950, CSA 22.2 No. 950, ICES-003 Class B, FCC Part 15 B, MITI, EMC, RoHS
Dimensions & Weight
Width:6.3 cm
Depth:8.4 cm
Height:15.2 cm
Weight:146 g
Manufacturer Warranty
Service & Support:Limited warranty - 5 years
Environmental Parameters
Min Operating Temperature:0 °C
Max Operating Temperature:40 °C
Humidity Range Operating:5 - 95%
Drop Specification:1.5 m to concrete
vis mere
The innovative LS 2208 hand-held scanner from Symbol Technologies delivers performance features at an affordable price to make your buying decision easier than ever. If you're seeking investment protection and great value in a small, light scanner that assures maximum productivity, then the LS 2208 is the ideal scanner for you.
From the checkout line to the back room, the LS 2208 helps you make the most of your application-specific solution in a variety of ways.
Getting started with the LS 2208 is fast and simple with 123Scan setup utility. This easy-to-use tool reduces startup time and costs wherever the scanner is used. To further save you money, the scan element in the LS 2208 is based on a liquid injection process that delivers integral shock protection, providing durability you can count on. These powerful features enable you to reduce downtime and keep maintenance costs to a minimum.
In any industry, the high-value LS 2208 hand-held scanner offers superior performance, excellent reliability and user-friendly ergonomics to create a more productive mobile environment. And when you choose the LS 2208, you receive the added assurance of purchasing from Symbol - a company with proven solutions and millions of scanner installations worldwide.
  • Durable single-board construction
  • Scratch-resistant tempered glass exit window
  • Accurate first-time capture of 1D bar codes
  • Wide working range
  • Multiple onboard interfaces
  • Plug-and-Play, with universal cable
  • Intuitive design
  • Ergonomic, lightweight design
  • Advanced Data Formatting (ADF)




The technical details come from 3rd party. edgemo is not responsible for any errors.
