Symbol LS2208 - barcode scanner

SKU LS2208-7AZU0300SR
Product Description:Symbol LS2208 - barcode scanner
Type:Barcode scanner - handheld - USB - decoded
Colour:Twilight black
Scan Element Type:Visible laser diode
Scan Speed:100 scan / sec
Connectivity Technology:Wired
Dimensions (WxDxH):6.3 cm x 8.4 cm x 15.2 cm
Not in stock
  • Specifications
  • Description
General
Type:Barcode scanner - handheld
Colour:Twilight black
Barcode
Interface Type:USB
Scan Element Type:Visible laser diode
Light Source Wave Length:650 nm
Scan Mode:Single-pass
Scan Speed:100 scan / sec
Max Working Distance:43 cm
Skew (Degrees):60
Pitch (Degrees):65
Print Contrast Signal (PCS):20%
Decode Capability:EAN/JAN, Code 93, Code 39, UCC/EAN-128, IATA, GS1 DataBar, Code 39 Full ASCII, Discrete 2 of 5, Codabar, Code 128, Code 11, UPC, Interleaved 2 of 5, MSI-Plessey, Code 128 Full ASCII
TTL Decoding:Decoded
Connectivity Technology:Wired
OK Notification:Beeper, LED indicator
Features:Advanced Data Formatting (ADF)
Expansion / Connectivity
Interfaces:1 x PoweredUSB
Miscellaneous
Included Accessories:Stand
Cables Included:1 x PoweredUSB cable - external - 2.1 m
Compliant Standards:VCCI, EN 60950, IEC950, UL 1950, CSA 22.2 No. 950, ICES-003 Class B, FCC Part 15 B, MITI, EMC, RoHS
Software
Software Included:Drivers & Utilities
Dimensions & Weight
Width:6.3 cm
Depth:8.4 cm
Height:15.2 cm
Weight:146 g
Manufacturer Warranty
Service & Support:Limited warranty - 5 years
Environmental Parameters
Min Operating Temperature:0 °C
Max Operating Temperature:50 °C
Humidity Range Operating:5 - 95%
Drop Specification:1.5 m to concrete
vis mere
The Symbol LS2208 handheld scanner delivers performance features at an affordable price to make your buying decision easier than ever. If you're seeking investment protection in a scanner that's small and light enough for maximum productivity, then the LS 2208 is the ideal scanner for you.
This USB kit includes LS2208-SR20007R Scanner, CBA-U03-S07ZAR USB Cable, 20-61019-02 Stand, SW-61077-02 CD ROM.
  • Durable single-board construction
  • Scratch-resistant tempered glass exit window
  • Accurate first-time capture of 1D bar codes
  • Wide working range
  • Multiple onboard interfaces
  • Plug-and-Play, with universal cable
  • Intuitive design
  • Ergonomic, lightweight design
  • Advanced Data Formatting (ADF)
