Printers & POSSymbol LS2208 - barcode scanner
SKU LS2208-7AZR0100ER
| Product Description: | Symbol LS2208 - barcode scanner |
| Type: | Barcode scanner - handheld - RS-232 - decoded |
| Colour: | Twilight black |
| Localisation: | EMEA |
| Minimum Bar Width: | 5 mil |
| Scan Element Type: | Visible laser diode |
| Scan Speed: | 100 scan / sec |
- Specifications
- Description
| General | |
| Type: | Barcode scanner - handheld |
| Colour: | Twilight black |
| Localisation: | EMEA |
| Barcode | |
| Interface Type: | RS-232 |
| Minimum Bar Width: | 5 mil |
| Scan Element Type: | Visible laser diode |
| Light Source Wave Length: | 650 nm |
| Scan Mode: | Single-pass |
| Scan Speed: | 100 scan / sec |
| Max Working Distance: | 76 cm |
| Skew (Degrees): | 60 |
| Pitch (Degrees): | 65 |
| Print Contrast Signal (PCS): | 20% |
| Decode Capability: | Code 93, Code 39, UCC/EAN-128, IATA, GS1 DataBar, Code 39 Full ASCII, Discrete 2 of 5, Codabar, Code 128, Code 11, UPC, Interleaved 2 of 5, MSI-Plessey, Code 128 Full ASCII, Code 39 Trioptic |
| TTL Decoding: | Decoded |
| Connectivity Technology: | Wired |
| OK Notification: | Beeper, LED indicator |
| Features: | Triggered, Advanced Data Formatting (ADF) |
| Expansion / Connectivity | |
| Interfaces: | 1 x RS-232 - DB-9 |
| Miscellaneous | |
| Included Accessories: | Stand |
| Cables Included: | 1 x serial cable - external |
| Compliant Standards: | Plug and Play, VCCI, EN 60950, IEC950, UL 1950, ICES-003 Class B, FCC Part 15 B, MITI, EMC, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 950, IEC 60825-1, CSA C22.2 No. 60950-1, EN 60825-1 |
| Power | |
| Power Device: | Power adapter |
| Electric Current Required: | 130 mA (typical), 175 mA (peak) |
| Dimensions & Weight | |
| Width: | 6.3 cm |
| Depth: | 8.4 cm |
| Height: | 15.2 cm |
| Weight: | 146 g |
| Manufacturer Warranty | |
| Service & Support: | Limited warranty - 5 years |
| Environmental Parameters | |
| Min Operating Temperature: | 0 °C |
| Max Operating Temperature: | 50 °C |
| Humidity Range Operating: | 5 - 95% (non-condensing) |
| Drop Specification: | 1.5 m to concrete |
The affordable LS2208 handheld bar code scanner provides fast, reliable scanning in an ergonomic, lightweight form. The wide working range - from near-contact to 17 inches - makes this device ideal for retail, hospital, education or government settings. Multiple on-board interfaces ensure integration with a variety of host systems.
- Durable single-board construction
- Scratch-resistant tempered glass exit window
- Accurate first-time capture of 1D bar codes
- Wide working range
- Multiple onboard interfaces
- Plug-and-Play, with universal cable
- Intuitive design
- Ergonomic, lightweight design
- Advanced Data Formatting (ADF)
The technical details come from 3rd party. edgemo is not responsible for any errors.
