Printers & POSSymbol LS1203 - barcode scanner
SKU LS1203-7AZU0100SR
| Product Description: | Symbol LS1203 - barcode scanner |
| Type: | Barcode scanner - handheld - USB - decoded |
| Colour: | Twilight black |
| Scan Element Type: | Visible laser diode |
| Scan Speed: | 100 scan / sec |
| Connectivity Technology: | Wired |
| Dimensions (WxDxH): | 6 cm x 18 cm x 6.2 cm |
- Specifications
- Description
| General | |
| Type: | Barcode scanner - handheld |
| Colour: | Twilight black |
| Barcode | |
| Interface Type: | USB |
| Scan Element Type: | Visible laser diode |
| Light Source Wave Length: | 650 nm |
| Scan Mode: | Single-pass |
| Scan Speed: | 100 scan / sec |
| Max Working Distance: | 20.32 cm |
| Skew (Degrees): | 60 |
| Pitch (Degrees): | 65 |
| Print Contrast Signal (PCS): | 30% |
| Decode Capability: | EAN/JAN, Code 93, Code 39, UCC/EAN-128, IATA, GS1 DataBar, Code 39 Full ASCII, Discrete 2 of 5, Codabar, Code 128, Code 11, UPC, Interleaved 2 of 5, MSI-Plessey, Code 128 Full ASCII, Code 39 Trioptic |
| TTL Decoding: | Decoded |
| Connectivity Technology: | Wired |
| OK Notification: | Beeper, LED indicator |
| Features: | Triggered, ESD (electrostatic discharge) safe, continuous mode scanning |
| Expansion / Connectivity | |
| Interfaces: | 1 x USB - Type A |
| Miscellaneous | |
| Included Accessories: | Stand |
| Cables Included: | 1 x USB cable - 2.1 m |
| Compliant Standards: | VCCI, EN 60950, UL 1950, IEC 825-1/EN 60825-1 class 1, CSA 22.2 No. 950, ICES-003 Class B, FCC Part 15 B, MITI, EMC, RoHS, IEC 950 |
| Power | |
| Power Device: | No power supply |
| Electric Current Required: | 100 mA (typical), 35 mA (standby) |
| Software | |
| Software Included: | Drivers & Utilities |
| Dimensions & Weight | |
| Width: | 6 cm |
| Depth: | 18 cm |
| Height: | 6.2 cm |
| Weight: | 122 g |
| Manufacturer Warranty | |
| Service & Support: | Limited warranty - 3 years |
| Environmental Parameters | |
| Min Operating Temperature: | 0 °C |
| Max Operating Temperature: | 50 °C |
| Humidity Range Operating: | 5 - 95% |
| Drop Specification: | 1.5 m to concrete |
The LS1203 handheld scanner from Symbol Technologies is designed to meet the needs of small retailers, delivering high quality laser scanning, user-friendly ergonomics and durability at an affordable price. From gift shops, boutiques, video and sporting goods stores to jewelers, florists and more, the LS1203 delivers the features, functionality and reliability needed to improve operational efficiencies from the checkout line to the back room - day in and day out. Manual keying is minimized, customers are charged the correct amount and paper-based inventory processes are automated. The result is faster checkout, increased customer satisfaction, increased employee productivity - and a rapid return on investment.
The kit includes LS1203-CR1007R scanner, CBA-U01-S017ZAR 7' straight USB cable, 20-73951-07R Stand and SW-75536-01 CD.
The kit includes LS1203-CR1007R scanner, CBA-U01-S017ZAR 7' straight USB cable, 20-73951-07R Stand and SW-75536-01 CD.
- Durable, single-board construction
- Multiple interfaces
- Sleek, lightweight, ergonomic design
- Intuitive scanning and plug-and-play capability
- Choice of triggered or continuous mode
The technical details come from 3rd party. edgemo is not responsible for any errors.
