WD Red SA500 WDS500G1R0B - SSD - 500 GB - SATA 6Gb/s

SKU WDS500G1R0B

Product Description:	WD Red SA500 WDS500G1R0B - SSD - 500 GB - SATA 6Gb/s
Type:	Solid state drive - internal
Capacity:	500 GB
Form Factor:	M.2 2280
Interface:	SATA 6Gb/s
Data Transfer Rate:	600 MBps
Features:	24x7 continuous operation, 3D NAND Technology

In Stock(1)

Specifications
Description
Accessories

General
Device Type:	Solid state drive - internal
Capacity:	500 GB
Form Factor:	M.2 2280
Interface:	SATA 6Gb/s
Features:	24x7 continuous operation, 3D NAND Technology
Width:	22 mm
Depth:	80 mm
Height:	2.38 mm
Weight:	7 g

Performance
SSD Endurance:	350 TB
Drive Transfer Rate:	600 MBps (external)
Internal Data Rate:	560 MBps (read) / 530 MBps (write)
4KB Random Read:	95000 IOPS
4KB Random Write:	85000 IOPS

Reliability
MTBF:	2,000,000 hours
24x7 Operation:	Yes

Expansion & Connectivity
Interfaces:	1 x SATA 6 Gb/s - M.2 Card
Compatible Bay:	M.2 2280

Power
Power Consumption:	52 mW (active) ¦ 2050 mW (read) ¦ 3550 Watt (write) ¦ 56 mW (sleep) ¦ 7 mW (DevSleep)

Miscellaneous
Compliant Standards:	FCC, UL, TUV, BSMI, KC, VCCI, Morocco

Manufacturer Warranty
Service & Support:	Limited warranty - 5 years

Environmental Parameters
Min Operating Temperature:	0 °C
Max Operating Temperature:	70 °C
Min Storage Temperature:	-55 °C
Max Storage Temperature:	85 °C
Shock Tolerance (non-operating):	1500 g @ 0.5 ms half-sine
Vibration Tolerance (operating):	5 g @ 10-2000 Hz
Vibration Tolerance (non-operating):	4.9 g @ 7-800 Hz

vis mere

Boost your NAS system's performance and responsiveness with the WD Red SA500 NAS SATA SSD. Your NAS system is always on, making a reliable drive essential. WD Red NAS SATA SSDs are specifically designed and tested for 24/7 usage. Their endurance and efficient caching makes them ideal for demanding applications.

Give it your tough workloads
Work more efficiently
Use it for your demanding applications

The technical details come from 3rd party. edgemo is not responsible for any errors.
