Printers & POSUbiquiti U Fiber UF-AE - fibre media converter - 10Mb LAN, 100Mb LAN, 1GbE
SKU UF-AE
| Product Description: | Ubiquiti U Fiber UF-AE - fibre media converter - 10Mb LAN, 100Mb LAN, 1GbE |
| Device Type: | Fibre media converter - SFP+ / RJ-45 |
| Form Factor: | External |
| Cabling Type: | 1000Base-T |
| Data Link Protocol: | 10Mb LAN, 100Mb LAN, 1GbE |
| Power Over Ethernet (PoE): | PoE |
| Dimensions (WxDxH): | 7.65 cm x 2.68 cm x 7.65 cm |
- Specifications
- Description
| General | |
| Device Type: | Fibre media converter |
| Form Factor: | External |
| Networking | |
| Connectivity Technology: | Wired |
| Cabling Type: | 1000Base-T |
| Data Link Protocol: | 10Mb LAN, 100Mb LAN, 1GbE |
| Status Indicators: | Power, status |
| Features: | Wall mountable, 12KV ESD Protector |
| Compliant Standards: | IEEE 802.3af |
| Expansion / Connectivity | |
| Interfaces: | 1 x Ethernet 1000Base-T (PoE) - RJ-45 female ¦ 1 x Ethernet 1000 - SFP+ female |
| Miscellaneous | |
| Compliant Standards: | IC, FCC |
| Power | |
| Power Over Ethernet (PoE): | PoE |
| Power Consumption Operational: | 1.5 Watt |
| Dimensions & Weight | |
| Width: | 7.65 cm |
| Depth: | 2.68 cm |
| Height: | 7.65 cm |
| Weight: | 70 g |
| Manufacturer Warranty | |
| Service & Support: | Limited warranty - 1 year |
| Environmental Parameters | |
| Min Operating Temperature: | -40 °C |
| Max Operating Temperature: | 60 °C |
| Humidity Range Operating: | 10 - 90% (non-condensing) |
The UFiber Active Ethernet is a 1 Gbps fiber-to-copper media converter; it allows ISPs to deliver active fiber to a customer's premises and connect it to affordable SOHO network equipment lacking SFP ports. Its compact design allows the UF-AE to be discreetly integrated into any environment.
Using fiber optic cable for data transport significantly reduces electrostatic discharge (ESD) failures and electromagnetic interference (EMI). Data integrity is also sustained in runs beyond 100 meters, the limit of Ethernet over twisted-pair cable. The UF-AE delivers data over long distances at high speed using fiber. The UF-AE provides fiber connectivity to an RJ45 Ethernet device, which in turn provides 802.3af or 24V passive PoE to the UF-AE.
Using fiber optic cable for data transport significantly reduces electrostatic discharge (ESD) failures and electromagnetic interference (EMI). Data integrity is also sustained in runs beyond 100 meters, the limit of Ethernet over twisted-pair cable. The UF-AE delivers data over long distances at high speed using fiber. The UF-AE provides fiber connectivity to an RJ45 Ethernet device, which in turn provides 802.3af or 24V passive PoE to the UF-AE.
- Module compatibility
- PoE convenience
- Supported speeds
- Status LEDs
- Indoor installation
The technical details come from 3rd party. edgemo is not responsible for any errors.
