Printers & POSSynology RackStation RS3621xs+ - NAS server
SKU RS3621XS+
| Product Description: | Synology RackStation RS3621xs+ - NAS server |
| Device Type: | NAS server |
| Host Connectivity: | Gigabit Ethernet / 10 Gigabit Ethernet |
| Enclosure Type: | Rack-mountable - 2U |
| Installed Devices / Modules Qty: | 0 (installed) / 12 (max) |
| Dimensions (WxDxH): | 48.2 cm x 72.4 cm x 8.8 cm |
| Weight: | 14.5 kg () |
- Specifications
- Description
| General | |
| Device Type: | NAS server |
| Host Connectivity: | Gigabit Ethernet / 10 Gigabit Ethernet |
| Enclosure Type: | Rack-mountable - 2U |
| Total Storage Capacity: | 0 GB |
| Installed Devices / Modules Qty: | 0 (installed) / 12 (max) |
| Width: | 48.2 cm |
| Depth: | 72.4 cm |
| Height: | 8.8 cm |
| Weight: | 14.5 kg () |
| Processor / Memory | |
| Processors Installed: | 1 x Intel Xeon D-1541 2.1 GHz |
| Number of Cores: | 8-core |
| Max Supported Qty: | 1 |
| Max Turbo Speed: | 2.7 GHz |
| RAM: | 8 GB (installed) / 64 GB (supported) - DDR4 |
| Storage Controller | |
| Type: | RAID |
| Interface Type: | SATA 6Gb/s |
| RAID Level: | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD, RAID F1, RAID 1 hot spare, RAID 10 hot spare, RAID 5 hot spare, RAID 6 hot spare, RAID F1 hot spare |
| Networking | |
| Data Link Protocol: | 1GbE, 10GbE |
| Network / Transport Protocol: | PPTP, L2TP, iSCSI, SMTP, FTP, DHCP, POP3, IMAP |
| Remote Management Protocol: | SNMP, Telnet, HTTPS |
| Network Services Compatibility: | Microsoft Active Directory (AD), Network File System (NFS), Server Message Block (SMB), Apple File Protocol (AFP), Web-based Distributed Authoring and Versioning (WebDAV), Calendaring Extensions to WebDAV (CalDAV) |
| Features: | Firewall protection, VPN support, LDAP support, VLAN support, wake on LAN (WOL), print server, antivirus analysis, High Availability, web server, backup server, file sharing, event log, Access Control List (ACL) support, iTunes server, DHCP server, FTP server, BitTorrent Client, e-mail server, bandwidth control, surveillance station, eMule client, e-mail notification |
| Encryption Algorithm: | 256-bit AES |
| Compliant Standards: | DLNA CERTIFIED |
| Expansion / Connectivity | |
| Expansion Bays: | 12 (total) / 12 (free) x hot-swap - 2.5" / 3.5" |
| Expansion Slots: | 2 (total) / 2 (free) x PCI Express 3.0 x8 ¦ 4 (total) / 3 (free) x DIMM 288-pin |
| Interfaces: | 4 x Ethernet 1000Base-T - RJ-45 ¦ 2 x USB 3.2 Gen 1 - Type A ¦ 2 x Ethernet 10Gb - RJ-45 ¦ 2 x expansion port ¦ 1 x management |
| Miscellaneous | |
| Compliant Standards: | FCC, BSMI, VCCI, RCM, EAC, CCC, KC, UL, RoHS |
| Included Accessories: | Accessory pack |
| Power | |
| Power Device: | Internal power supply |
| Installed Qty: | 2 |
| Max Supported Qty: | 2 |
| Power Redundancy: | Yes |
| Power Redundancy Scheme: | 1+1 |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational: | 142.5 Watt |
| Power Provided: | 500 Watt |
| Manufacturer Warranty | |
| Service & Support: | Limited warranty - 5 years |
| Environmental Parameters | |
| Min Operating Temperature: | 0 °C |
| Max Operating Temperature: | 35 °C |
| Humidity Range Operating: | 5 - 95% |
| Sound Emission: | 50.2 dBA |
High-performance enterprise storage built for data accuracy and security.
- Accelerate your business operations
- Storage you can trust
- Redundant power
- Maximize service availability
- Next-generation file system
- Tailored to your business
- Hyper Backup
- Snapshot replication
- Active backup suite
The technical details come from 3rd party. edgemo is not responsible for any errors.
