StarTech.com Multimode (MM) LC Fiber Media Converter for 10/100/1000 Network - 550m - Gigabit Ethernet - 850nm - with SFP Transceiver (MCM1110MMLC) - fibre media converter - 10Mb LAN, 100Mb LAN, 1GbE
SKU MCM1110MMLC
Product Description: | StarTech.com Multimode (MM) LC Fiber Media Converter for 10/100/1000 Network - 550m - Gigabit Ethernet - 850nm - with SFP Transceiver (MCM1110MMLC) - fibre media converter - 10Mb LAN, 100Mb LAN, 1GbE |
Device Type: | Fibre media converter - RJ-45 / LC multi-mode |
Form Factor: | External |
Cabling Type: | 10Base-T, 1000Base-LX, 1000Base-SX, 100Base-TX, 1000Base-T |
Data Transfer Rate: | 1 Gbps |
Optical Wave Length: | 850 nm |
Data Link Protocol: | 10Mb LAN, 100Mb LAN, 1GbE |
- Specifications
- Description
General | |
Device Type: | Fibre media converter |
Form Factor: | External |
Colour: | Brown |
Networking | |
Connectivity Technology: | Wired |
Cabling Type: | 10Base-T, 1000Base-LX, 1000Base-SX, 100Base-TX, 1000Base-T |
Data Link Protocol: | 10Mb LAN, 100Mb LAN, 1GbE |
Data Transfer Rate: | 1 Gbps |
Optical Wave Length: | 850 nm |
Max Transfer Distance: | 550 m |
Features: | Auto-negotiation, auto-uplink (auto MDI/MDI-X), Link Fault Pass Through function (LFP), Jumbo Frames support, metal housing |
Compliant Standards: | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab |
Expansion / Connectivity | |
Interfaces: | 1 x Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 female ¦ 1 x Ethernet 1000Base-LX/1000Base-SX - LC multi-mode female x 2 |
Miscellaneous | |
MTBF: | 50,000 hours |
Compliant Standards: | FCC, RoHS, MSA |
Power | |
Power Device: | External power adapter |
Voltage Required: | AC 120/230 V |
Power Consumption Operational: | 5 Watt |
Dimensions & Weight | |
Width: | 7 cm |
Depth: | 2.6 cm |
Height: | 9.7 cm |
Weight: | 200 g |
Manufacturer Warranty | |
Service & Support: | Limited warranty - 2 years |
Environmental Parameters | |
Min Operating Temperature: | 0 °C |
Max Operating Temperature: | 50 °C |
Humidity Range Operating: | 5 - 95% (non-condensing) |
Compatibility Information | |
Designed For: | P/N: SVA5N3NEUA |
Convert and extend different networks over a Gigabit fiber cable connection up to 550m / 1804ft. This fiber media converter offers an easy, cost-effective way to extend your network over Gigabit fiber. It is equipped with a multimode transceiver which converts a copper RJ45 Ethernet connection to Gigabit fiber to extend your network over longer distances or connect workstations to switches. The converter provides a powerful extended networking solution for campuses, businesses, government facilities, stadiums, or other areas requiring network access.
The Gigabit Fiber Media Converter provides a cost-effective and dependable solution for shorter range network extensions. It connects an Ethernet network to remote devices over a fiber backbone, with a 550m range on the fiber optic interface. The media converter has a durable metal housing, engineered to deliver long-lasting performance.
Fully compatible with 10/100/1000Base-T Ethernet networks, the fiber media converter supports auto negotiation to bridge different speed networks and devices to a Gigabit fiber network. It provides versatile connectivity to your existing networks and devices, allowing you to maximize the usage and performance of legacy equipment.
The multimode transceiver is removable, giving you the flexibility to change your transceiver in the future to meet your networking needs.
The unmanaged fiber media converter has a standalone design with simple plug-and-play set-up to ensure fast and easy installation. Compact in size, the converter gives you flexible installation options - including a wall mounting option to save space.
The Gigabit Fiber Media Converter provides a cost-effective and dependable solution for shorter range network extensions. It connects an Ethernet network to remote devices over a fiber backbone, with a 550m range on the fiber optic interface. The media converter has a durable metal housing, engineered to deliver long-lasting performance.
Fully compatible with 10/100/1000Base-T Ethernet networks, the fiber media converter supports auto negotiation to bridge different speed networks and devices to a Gigabit fiber network. It provides versatile connectivity to your existing networks and devices, allowing you to maximize the usage and performance of legacy equipment.
The multimode transceiver is removable, giving you the flexibility to change your transceiver in the future to meet your networking needs.
The unmanaged fiber media converter has a standalone design with simple plug-and-play set-up to ensure fast and easy installation. Compact in size, the converter gives you flexible installation options - including a wall mounting option to save space.
The technical details come from 3rd party. edgemo is not responsible for any errors.
