MSI MAG A750BN PCIE5 - power supply - 750 Watt

SKU MAG A750BN PCIE5
Product Description:MSI MAG A750BN PCIE5 - power supply - 750 Watt
Device Type:Power supply - active Power Factor Correction (PFC) - internal
Specification Compliance:ATX12V / EPS12V
80 PLUS Certification:80 PLUS Bronze
Weight:2.8 kg
Input Voltage:AC 100-240 V
Output Voltage:+3.3, +5, ±12 V
17-07-2025
Login for price
  • Specifications
  • Description
  • Accessories
General
Device Type:Power supply - active Power Factor Correction (PFC) - internal
Specification Compliance:ATX12V / EPS12V
PSU Form Factor:ATX
Power Device
Input Voltage:AC 100-240 V
Frequency Required:50 - 60 Hz
Power Output Connectors Details:1 x power 24 pin ATX ¦ 2 x power 8 pin EPS12V with detachable 4 pin ATX12V section ¦ 1 x 12+4 pin PCI Express 5.0 power ¦ 2 x 8 pin PCI Express power with detachable 2 pin section ¦ 5 x 15 pin Serial ATA power ¦ 2 x 4 PIN internal power ¦ 1 x 4 PIN internal power
Output Voltage:+3.3, +5, ±12 V
Power Capacity:750 Watt
Output Current:+3.3V - 20 A ¦ +5V - 20 A ¦ -12V - 0.3 A ¦ +12V - 62.5 A ¦ +5VSB - 2.5 A
Efficiency:85%
80 PLUS Certification:80 PLUS Bronze
Miscellaneous
Cables Included:ATX power cable 60 cm ¦ 16-pin 12VHPWR power cable 60 cm ¦ 8 pin PCI Express to 2x6 pin PCI Express power adapter 60 cm ¦ Power 15 pin SATA cable ¦ 2 x power 8 pin EPS12V modular cable 65 cm ¦ Power 15 pin SATA to 4 pin adapter ¦ AC input cable - external
Cooling System:120 mm fan
Features:Overpower protection, over current protection, short-circuit protection, over voltage protection, overheat protection, sleeve bearing cooling fan, DC-DC technology
Manufacturer Warranty
Service & Support:5-year warranty
Dimensions & Weight
Width:15 cm
Depth:14 cm
Height:8.6 cm
Weight:2.8 kg
vis mere
  • PCIe 5.0 compliant
  • 80 PLUS Bronze certified
  • Compact sizing
  • All the more organized




The technical details come from 3rd party. edgemo is not responsible for any errors.
