Lenovo ThinkSystem ST250 V2 - tower Xeon E-2378 2.6 GHz - 32 GB - no HDD
SKU 7D8FA01YEA
Product Description: | Lenovo ThinkSystem ST250 V2 - tower Xeon E-2378 2.6 GHz - 32 GB - no HDD |
Type: | Server - tower |
Height (Rack Units): | 4U |
Localisation: | Region: EMEA |
Server Scalability: | 1-way |
Processor: | 1 x Intel Xeon E-2378 / 2.6 GHz (up to 4.8 GHz, (8-core) |
Processor Socket: | LGA1200 Socket |
- Specifications
- Description
General | |
Type: | Server |
Product Form Factor: | Tower - 4U |
Built-in Devices: | Led panel |
Embedded Security: | Trusted Platform Module (TPM 2.0) Security Chip |
Server Scalability: | 1-way |
Front Accessible Bays Qty: | 2 |
Hot-Swap Bays Qty: | 8 |
Localisation: | Region: EMEA |
Processor / Chipset | |
CPU: | Intel Xeon E-2378 |
Clock Speed: | 2.6 GHz |
Max Turbo Speed: | 4.8 GHz |
Number of Cores: | 8-core |
CPU Qty: | 1 |
Max CPU Qty: | 1 |
CPU Socket: | LGA1200 Socket |
Chipset Type: | Intel C256 |
Cache Memory | |
Installed Size: | 16 MB |
Cache Per Processor: | 16 MB |
RAM | |
Installed Size: | 32 GB (installed) / 128 GB (max) |
Technology: | DDR4 SDRAM - ECC |
Effective Memory Speed: | 3200 MHz |
Rated Memory Speed: | 3200 MHz |
Form Factor: | DIMM 288-pin |
Slots: | 4 (Total) / 3 (empty) |
Features: | Unbuffered, TruDDR4 |
Configuration Features: | 1 x 32 GB |
Hard Drive | |
Type: | No HDD |
Storage Controller | |
Type: | 1 x RAID - PCIe 3.0 x8 |
Controller Interface Type: | SATA 6Gb/s / SAS 12Gb/s |
Storage Controller Name: | ThinkSystem RAID 5350-8i |
Channel Qty: | 8 |
RAID Level: | RAID 0, RAID 1, RAID 10, RAID 5, JBOD |
Optical Storage | |
Type: | No optical drive |
Monitor | |
Monitor Type: | None. |
Graphics Controller | |
Graphics Processor: | Matrox G200 |
Video Memory: | 16 MB |
Video Interfaces: | VGA |
Networking | |
Ethernet Ports: | 2 x Gigabit Ethernet |
Ethernet Controller: | Broadcom BCM5720 |
Data Link Protocol: | Ethernet, Gigabit Ethernet, Fast Ethernet |
Remote Management Controller: | XClarity Controller (XCC) Enterprise |
Features: | PXE support, Teaming support |
Expansion / Connectivity | |
Bays: | 2 (total) / 2 (free) x external 5.25" x 1/2H ¦ 8 (total) / 8 (free) x hot-swap 2.5" |
Slots: | 2 (total) / 2 (free) x PCIe 3.0 x4 - half-length, full-height ¦ 1 PCIe 4.0 x16 - half-length, full-height ¦ PCIe 3.0 x4 - half-length, full-height (x8 mode) |
Interfaces: | 1 x USB 3.2 Gen 1 (1 in front) ¦ 1 x USB 2.0 (1 in front) ¦ 4 x USB 3.2 Gen 2 ¦ 1 x serial ¦ 1 x VGA ¦ 2 x LAN (Gigabit Ethernet) - RJ-45 ¦ 1 x management - RJ-45 ¦ 1 x USB 3.0 (1 internal) |
Miscellaneous | |
Theft/Intrusion Protection: | Security lock slot (cable lock sold separately), padlock loop, chassis intrusion switch |
Security Slot Type: | Kensington security slot |
Compliant Standards: | ASHRAE Class A2, NIST SP800-147B, VCCI Class A, ANSI, UL 62368-1, IEC 62368-1, CB, FCC Part 15 A, ICES-003 issue 7 Class A, CSA C22.2 No. 62368-1, CISPR 32 Class A, IEC 60950-1, UKCA, EN 55032 Class A, EN 62368-1, EN55024, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 50581-1, KN32 Class A, TP EAC 037/2016, TP TC 004/2011, TP TC 020/2011, AS/NZS CISPR 32 Class A, AS/NZS 62368.1, UL, GREENGUARD, UL 2819, CCC, GB 17625.1, GB 4943.1, GB/T9254, CECP, CQC3135, CELP, HJ 2507-2011, NOM-019, TUV GS, EK1-ITB2000, GS, INMETRO, Morocco, KN35, EAC, NRCS, LoA, Energy-Related Products (ErP) Lot 9, BSMI CNS 13438 Class A, NSF/ANSI 426 |
Power | |
Device Type: | Power supply - hot-plug |
Power Redundancy: | Optional |
Power Redundancy Scheme: | 1+1 (with optional power supply) |
Installed Qty: | 1 |
Max Supported Qty: | 2 |
Voltage Required: | AC 100-240 V (50/60 Hz) |
Power Provided: | 550 Watt |
80 PLUS Certification: | 80 PLUS Platinum |
Operating System / Software | |
OS Provided: | No operating system |
Sustainability Information | |
EPEAT Compliant: | EPEAT Bronze |
ENERGY STAR Certified: | Yes |
ENERGY STAR Version: | 3.0 |
Manufacturer Warranty | |
Service & Support: | Limited warranty - 3 years - on-site - response time: next business day |
Dimensions & Weight | |
Width: | 17.6 cm |
Depth: | 57.8 cm |
Height: | 44.4 cm |
Weight: | 23.6 kg |
Environmental Parameters | |
Min Operating Temperature: | 10 °C |
Max Operating Temperature: | 35 °C |
Humidity Range Operating: | 8 - 80% |
The Lenovo ThinkSystem ST250 V2 is a mainstream 1-socket tower server that also be rack mounted as a rack server. It is ideal for small-to-medium businesses, remote offices, branch offices, banking and public sector. The server supports the new Intel Xeon E-2300 Series processors, formerly codenamed "Rocket Lake".
- Up to four 3200 MHz DDR4 ECC UDIMMs provide speed and capacity of up to 128 GB
- Four PCIe slots for I/O expansion, one of which has the new PCIe Gen4 interface to maximize I/O performance
- New high-speed RAID controllers from Lenovo and Broadcom provide 12 Gb SAS connectivity to the drive backplanes
- Offers two 5.25-inch media bays with support for optical drives or backup drives
- Supports two M.2 drives for OS boot support with RAID redundancy
- The server has two integrated Gigabit Ethernet ports
- The server offers one PCIe 4.0 slot plus three PCIe 3.0 I/O expansion slots
- Support for a NVIDIA GPU for enhanced workload performance
