Lenovo ThinkSystem - network adapter - LAN-on-motherboard (LOM) - Gigabit Ethernet x 2

SKU 7ZT7A00544
Product Description:Lenovo ThinkSystem - network adapter - LAN-on-motherboard (LOM) - Gigabit Ethernet x 2
Device Type:Network adapter
Form Factor:Plug-in card
Interface (Bus) Type:LAN-on-motherboard (LOM)
Ports:Gigabit Ethernet x 2
Data Link Protocol:1GbE
Data Transfer Rate:1 Gbps
01-07-2024
  • Specifications
  • Description
General
Device Type:Network adapter
Form Factor:Plug-in card
Interface (Bus) Type:LAN-on-motherboard (LOM)
Networking
Ports:Gigabit Ethernet x 2
Connectivity Technology:Wired
Data Link Protocol:Gigabit Ethernet
Data Transfer Rate:1 Gbps
Capacity:Virtual functions: 128
Remote Management Protocol:RMON
Features:Flow control, VLAN support, WOL, IPv6 support, QoS, RDMA support, VMDq, PXE support, LSO, RSS, UEFI support, LACP, Energy Efficient Ethernet, CoS, tagged VLAN, MSI-X, TCP/IP checksum offload, UDP/IP checksum offload, VEPA, NC-SI, VXLAN, NVGRE, VEB, TPH, Advanced Packet Filtering, Intel VT, Jumbo Frames support (up to 9728 bytes)
Compliant Standards:IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1as, IEEE 802.1Qbg
Processor / Memory
Processor:2 x Marvell 88E1514
Expansion / Connectivity
Interfaces:2 x Ethernet 1000 - RJ-45
Miscellaneous
Compliant Standards:ICES-003 Class A, RoHS, UL 60950-1 Second Edition, FCC Part 15 A, KCC Class A, VCCI Class A, RCM, RRA Class A
Software / System Requirements
Software Included:Intel PROSet
OS Required:Microsoft Windows Server 2012 R2, SuSE Linux Enterprise Server 11 SP4, Microsoft Windows Server 2016, VMware ESXi 6.5, Red Hat Enterprise Linux 7.3, Red Hat Enterprise Linux 6.9, SuSE Linux Enterprise Server 12 SP2, VMware ESXi 6.0 update 3
Manufacturer Warranty
Service & Support:Limited warranty - 1 year
Compatibility Information
Designed For:Lenovo ThinkAgile VX 1U Certified Node 7Y93 ¦ Lenovo ThinkAgile VX Certified Node 7Y94, 7Z12 ¦ Lenovo ThinkAgile VX7820 Appliance 7Z13 ¦ Lenovo ThinkSystem SR530 ¦ Lenovo ThinkSystem SR550 ¦ Lenovo ThinkSystem SR570 ¦ Lenovo ThinkSystem SR590 ¦ Lenovo ThinkSystem SR630 ¦ Lenovo ThinkSystem SR650 ¦ Lenovo ThinkSystem SR850 ¦ Lenovo ThinkSystem SR860 ¦ Lenovo ThinkSystem SR950
vis mere
The controller connects to available 10 GbE and 1 Gigabit Ethernet LAN-on-motherboard (LOM) adapter cards and onboard connectors to provide a comprehensive 1 GbE / 10 GbE networking solution for ThinkSystem customers.
  • Low latency
  • Virtualization performance
  • Next-generation VMDq
  • VM load balancing




The technical details come from 3rd party. edgemo is not responsible for any errors.
