Lenovo ThinkPad - wireless cellular modem - 5G

SKU 4XC1D11452

Product Description:	Lenovo ThinkPad - wireless cellular modem - 5G
Device Type:	Wireless cellular modem - M.2 Card (PCIe 3.0)
Form Factor:	Internal
Max Transfer Rate:	2 Gbps
Mobile Band:	LTE B1/B12/B13/B14/B17/B18/B19/B2/B20/B25/B26/B28/B29/B3/B30/B32/B34/B38/B39/B4/B40/B41/B42/B48/B5/B66/B7/B71 / 5G n1/n12/n2/n20/n28/n3/n41/n5/n66/n7/n71/n77/n78/n79/n8
System Requirements:	Windows 10
Dimensions (WxDxH):	3 cm x 4.2 cm x 0.25 cm

Not in stock

Specifications
Description
Accessories

General
Device Type:	Wireless cellular modem
Form Factor:	Internal

Modem
Bus:	M.2 Card
PCI Revision:	PCIe 3.0
Connectivity Technology:	Wireless
Max Transfer Rate:	2 Gbps
Mobile Band:	LTE B1/B12/B13/B14/B17/B18/B19/B2/B20/B25/B26/B28/B29/B3/B30/B32/B34/B38/B39/B4/B40/B41/B42/B48/B5/B66/B7/B71 / 5G n1/n12/n2/n20/n28/n3/n41/n5/n66/n7/n71/n77/n78/n79/n8

Networking
Features:	4x4 MIMO technology

Miscellaneous
Compliant Standards:	KCC, TELEC, NCC, RCM, UKCA
Package Type:	OEM

Software / System Requirements
OS Required:	Windows 10

Manufacturer Warranty
Service & Support:	Limited warranty - 1 year

Dimensions & Weight
Width:	3 cm
Depth:	4.2 cm
Height:	0.25 cm
Weight:	8 g

Dimensions & Weight (Shipping)
Shipping Width:	5.4 cm
Shipping Depth:	14.4 cm
Shipping Height:	17.7 cm
Shipping Weight:	70 g

Environmental Parameters
Min Operating Temperature:	-10 °C
Max Operating Temperature:	55 °C
Humidity Range Operating:	5 - 95%

Compatibility Information
Designed For:	Lenovo ThinkPad X1 Nano Gen 1 20UN (WWAN upgradable), 20UQ (WWAN upgradable)

vis mere

The Lenovo ThinkPad combines robust performance with versatile connectivity options, making it suitable for various environments and situations. With an operational temperature range from -10°C to 55°C and a humidity range of 5% to 95%, this device is designed to withstand diverse conditions. Its advanced 5G cellular modem and support for LTE bands ensure reliable and fast wireless connectivity, allowing for seamless mobile broadband access. Equipped with 4x4 MIMO technology, the Lenovo ThinkPad offers enhanced data transmission capabilities, supporting a maximum transfer rate of 2 Gbps. The device complies with several standards including KCC, TELEC, NCC, RCM, and UKCA, ensuring adherence to regional regulations. Windows 10 is required for optimal operation, providing a familiar and powerful platform for various applications.

Designed for extreme operating conditions
5G connectivity for fast and reliable performance
Supports a wide range of LTE bands
Equipped with advanced 4x4 MIMO technology
Compliant with multiple international standards

The technical details come from 3rd party. edgemo is not responsible for any errors.
