Lenovo ThinkPad Ultra Docking Station - docking station - VGA, HDMI, 2 x DP

SKU 40AJ0135EU

Product Description:	Lenovo ThinkPad Ultra Docking Station - docking station - VGA, HDMI, 2 x DP
Product Type:	Docking station
Video Interfaces:	VGA, HDMI, 2 x DP
Dimensions (WxDxH):	37.8 cm x 15.9 cm x 5.41 cm
Weight:	810 g
Localisation:	Korea, Europe
Power:	Power adapter 135 Watt Power Provided

06-12-2024

Specifications
Description
Accessories

General
Product Type:	Docking station
Width:	37.8 cm
Depth:	15.9 cm
Height:	5.41 cm
Weight:	810 g
Localisation:	Korea, Europe

Video
Max Resolution Details:	4096 x 2160 - 60 Hz (DisplayPort only) ¦ 4096 x 2160 - 60 Hz (HDMI only) ¦ 2048 x 1536 - 85 Hz (VGA only) ¦ 4096 x 2160@30Hz, 4096 x 2160@30Hz (DisplayPort and HDMI simultaneously) ¦ 4096 x 2160@30Hz, 4096 x 2160@30Hz (DisplayPort1 and DisplayPort2 simultaneously) ¦ 4096 x 2160@60Hz, 2048 x 1536@85Hz (DisplayPort and VGA simultaneously) ¦ 4096 x 2160@60Hz, 2048 x 1536@85Hz (HDMI and VGA simultaneously) ¦ 4096 x 2160@60Hz, 1920 x 1080@60Hz, 1920 x 1080@60Hz (DisplayPort1 and DisplayPort2 and HDMI simultaneously) ¦ 4096 x 2160@30Hz, 4096 x 2160@30Hz, 2048 x 1536@85Hz (DisplayPort and HDMI and VGA simultaneously)

Video

Max Resolution Details:

4096 x 2160 - 60 Hz (DisplayPort only) ¦ 4096 x 2160 - 60 Hz (HDMI only) ¦ 2048 x 1536 - 85 Hz (VGA only) ¦ 4096 x 2160@30Hz, 4096 x 2160@30Hz (DisplayPort and HDMI simultaneously) ¦ 4096 x 2160@30Hz, 4096 x 2160@30Hz (DisplayPort1 and DisplayPort2 simultaneously) ¦ 4096 x 2160@60Hz, 2048 x 1536@85Hz (DisplayPort and VGA simultaneously) ¦ 4096 x 2160@60Hz, 2048 x 1536@85Hz (HDMI and VGA simultaneously) ¦ 4096 x 2160@60Hz, 1920 x 1080@60Hz, 1920 x 1080@60Hz (DisplayPort1 and DisplayPort2 and HDMI simultaneously) ¦ 4096 x 2160@30Hz, 4096 x 2160@30Hz, 2048 x 1536@85Hz (DisplayPort and HDMI and VGA simultaneously)

Expansion / Connectivity
Interfaces:	1 x USB 3.1 Gen 2 with Always-on charging ¦ 3 x USB 3.1 Gen 2 ¦ 2 x USB-C ¦ 1 x network - 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 2 x audio / video - DisplayPort - 20 pin DisplayPort ¦ 1 x audio / video - HDMI - 19 pin HDMI Type A ¦ 1 x display / video - VGA - 15 pin HD D-Sub (HD-15) ¦ 1 x audio - headphones/microphone - mini-phone stereo 3.5 mm ¦ 1 x docking / port replicator

Miscellaneous
Included Accessories:	2 x security keys
Features:	Security lock slot (cable lock sold separately), wake on LAN, Preboot Execution Environment (PXE) support, MAC address pass-through
Compliant Standards:	UL, cUL, NOM, FCC, ICES

Power
Power Device:	Power adapter
Power Provided:	135 Watt

Manufacturer Warranty
Service & Support:	Limited warranty - 3 years

Dimensions & Weight (Shipping)
Shipping Width:	42.2 cm
Shipping Depth:	20 cm
Shipping Height:	8.6 cm
Shipping Weight:	2 kg

Environmental Parameters
Min Operating Temperature:	0 °C
Max Operating Temperature:	35 °C

vis mere

Lenovo ThinkPad Ultra Docking Station provides excellent docking experience for Large Enterprise ThinkPad customers. The innovative side connector, designed exclusively for ThinkPad notebooks, provides a driver-free way to connect conveniently and securely to a range of USB accessories and external displays, while rapid charging support and a mirrored power button make going mobile even easier. Designed for large enterprise environments, ThinkPad. Docking Stations support PXE book, Wake-on-LAN, and MAC address pass-through, simplifying asset management for IT managers. Painstakingly crafted and extensively tested, ThinkPad Docking Stations provide a seamless docking experience for professionals.

Innovative side connection, exclusively for ThinkPad notebooks
Designed with Enterprise IT in mind
Upgraded performance

The technical details come from 3rd party. edgemo is not responsible for any errors.
