Printers & POSLenovo ThinkCentre M90q Gen 5 - tiny Core i7 i7-14700 2.1 GHz - vPro Enterprise - 32 GB - SSD 2 x 512 GB - Nordic (Danish/Finnish/Norwegian/Swedish)
SKU 12TH001HMX
| Product Description: | Lenovo ThinkCentre M90q Gen 5 - tiny Core i7 i7-14700 2.1 GHz - vPro Enterprise - 32 GB - SSD 2 x 512 GB - Nordic (Danish/Finnish/Norwegian/Swedish) |
| Type: | Personal computer - tiny |
| Bundled Services: | 3 Years Lenovo Premier Support |
| Platform Technology: | Intel vPro Enterprise |
| Localisation: | Language: English, Nordic / region: Denmark, Finland, Norway, Sweden |
| Processor: | Intel Core i7 (14th Gen) i7-14700 / 2.1 GHz (up to 5.4 GHz, (20-core) |
| Cache Memory: | 33 MB |
- Specifications
- Description
| General | |
| Platform Technology: | Intel vPro Enterprise |
| Type: | Personal computer |
| Bundled Services: | 3 Years Lenovo Premier Support |
| Product Form Factor: | Tiny |
| Built-in Devices: | Speaker |
| Embedded Security: | Discrete Trusted Platform Module (TPM 2.0) Security Chip |
| Colour: | Black |
| Localisation: | Language: English, Nordic / region: Denmark, Finland, Norway, Sweden |
| Processor / Chipset | |
| CPU: | Intel Core i7 (14th Gen) i7-14700 |
| Clock Speed: | 2.1 GHz (P-core) / 1.5 GHz (E-core) |
| Max Turbo Speed: | 5.4 GHz (P-core) / 4.2 GHz (E-core) |
| Number of Cores: | 20-core |
| CPU Qty: | 1 |
| Max CPU Qty: | 1 |
| Chipset Type: | Intel Q670 |
| Cache Memory | |
| Installed Size: | 33 MB |
| Cache Per Processor: | 33 MB |
| RAM | |
| Installed Size: | 32 GB (installed) / 64 GB (max) |
| Technology: | DDR5 SDRAM |
| Rated Memory Speed: | 5600 MHz |
| Form Factor: | SO-DIMM 262-pin |
| Slots: | 2 (Total) / 0 (empty) |
| Features: | Dual channel memory architecture |
| Configuration Features: | 2 x 16 GB |
| Hard Drive | |
| Type: | SSD - M.2 2280 |
| Capacity: | 2 x 512 GB |
| Interface Type: | PCI Express 4.0 x4 |
| Features: | TCG Opal Encryption 2, NVM Express (NVMe), Performance |
| Optical Storage | |
| Type: | No optical drive |
| Monitor | |
| Monitor Type: | None. |
| Graphics Controller | |
| Graphics Processor: | Intel UHD Graphics 770 Shared Video Memory (UMA) |
| Audio Output | |
| Compliant Standards: | High Definition Audio |
| Speakers Included: | 1 x tweeter |
| Input Device | |
| Type: | Mouse, keyboard |
| Keyboard | |
| Keyboard Name: | Lenovo Traditional Keyboard |
| Interface: | USB |
| Localization & Layout: | Nordic (Danish/Finnish/Norwegian/Swedish) |
| Mouse | |
| Mouse Name: | Lenovo Calliope Mouse |
| Interface: | USB |
| Networking | |
| Ethernet Ports: | 1 x 2.5 Gigabit Ethernet, 1 x Gigabit Ethernet |
| Wireless LAN Supported: | Yes |
| Wireless NIC: | Intel Wi-Fi 6E AX 211 |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3 |
| Features: | Dual stream (2x2) |
| Expansion / Connectivity | |
| Slots: | 1 PCIe 4.0 x8 - low-profile ¦ 2 M.2 Card (for SSD) ¦ 1 M.2 Card (for WLAN) |
| Interfaces: | 2 x USB 3.2 Gen 1 (2 rear) (one of them supports SmartPower On) ¦ 4 x USB 3.2 Gen 2 (2 front, 2 rear) (one of them is Always On, fast-charging (5V, 2.1A)) ¦ 1 x HDMI (1 rear) (TMDS compatible) ¦ 1 x DisplayPort 1.4a (1 rear) ¦ 1 x LAN (Gigabit Ethernet) - RJ-45 (1 rear) ¦ 1 x USB-C 3.2 Gen 2x2 (1 front) (data only) ¦ 1 x headphones/microphone (1 front) ¦ 1 x DisplayPort (1 rear) |
| Miscellaneous | |
| Included Accessories: | VESA mounting kit, toolless chassis screw |
| Theft/Intrusion Protection: | Security lock slot (cable lock sold separately), chassis intrusion switch |
| Security Slot Type: | Kensington security slot |
| VESA Mounting Interface: | VESA |
| Compliant Standards: | RoHS, FIPS 140-2, Energy-Related Products (ErP) Lot 3, TCG Certified, TCO Certified 9.0 |
| Manufacturer Selling Program: | Lenovo TopSeller |
| Power | |
| Device Type: | Power adapter |
| Voltage Required: | AC 100-240 V (50/60 Hz) |
| Power Provided: | 230 Watt |
| Efficiency: | 89% |
| Operating System / Software | |
| OS Provided: | Windows 11 Pro Danish / English / Finnish / Norwegian / Swedish |
| Sustainability Information | |
| EPEAT Compliant: | EPEAT Gold |
| ENERGY STAR Certified: | Yes |
| ENERGY STAR Version: | 8.0 |
| Manufacturer Warranty | |
| Service & Support: | Base warranty - 3 years - on-site ¦ Extended warranty - 3 years - on-site - response time: next business day |
| Dimensions & Weight | |
| Width: | 17.9 cm |
| Depth: | 18.29 cm |
| Height: | 3.65 cm |
| Weight: | 1.25 kg |
| Environmental Parameters | |
| Min Operating Temperature: | 5 °C |
| Max Operating Temperature: | 35 °C |
| Humidity Range Operating: | 20 - 80% |
The Lenovo ThinkCentre M90q Gen 5 is designed for efficiency and compactness, offering a powerful computing experience in an ultra-small form factor. This personal computer features an Intel Core i7 processor with 20 cores and a clock speed of 2.1 GHz, ensuring smooth multitasking and efficient operation for any workload. With DDR5 SDRAM for rapid data processing and a built-in trusted platform module for enhanced security, this device is built to handle demanding tasks securely. Equipped with PCI Express 4.0 x4 SSD storage, the system delivers quick data access and storage performance. The connectivity options are plentiful, featuring multiple USB ports, HDMI, and DisplayPort interfaces, enabling integration with peripherals. EPEAT Gold and ENERGY STAR certifications reflect its environmentally conscious design, allowing users to operate sustainably while meeting their performance needs.
- Compact ultra-small form factor for space-saving efficiency
- Powerful Intel Core i7 processor with 20 cores for high performance
- High-speed DDR5 RAM for efficient multitasking
- Ample connectivity options including USB 3.2, HDMI, and Ethernet
- EPEAT Gold and ENERGY STAR certifications for eco-friendly operation
The technical details come from 3rd party. edgemo is not responsible for any errors.
