Printers & POSIntel Server System LSVRP4304ES6XXR - rack-mountable - Xeon E3-1230V6 3.5 GHz - 16 GB
SKU LSVRP4304ES6XXR
| Product Description: | Intel Server System LSVRP4304ES6XXR - rack-mountable - Xeon E3-1230V6 3.5 GHz - 16 GB |
| Type: | Server - rack-mountable |
| Height (Rack Units): | 4U |
| Processor: | 1 x Intel Xeon E3-1230V6 / 3.5 GHz (, up to 3.9 GHz, (Quad-Core) |
| Cache Memory: | 8 MB |
| Cache Per Processor: | 8 MB |
| RAM: | 16 GB (installed) / 64 GB (max) - DDR4 SDRAM - ECC |
- Specifications
- Description
| General | |
| Type: | Server |
| Product Form Factor: | Rack-mountable - 4U |
| Embedded Security: | Trusted Platform Module (TPM 2.0) Security Chip |
| Internal Bays Qty: | 1 |
| Front Accessible Bays Qty: | 4 |
| Processor / Chipset | |
| CPU: | Intel Xeon E3-1230V6 |
| Clock Speed: | 3.5 GHz |
| Max Turbo Speed: | 3.9 GHz |
| Number of Cores: | Quad-Core |
| CPU Qty: | 1 |
| Max CPU Qty: | 1 |
| Chipset Type: | Intel C236 |
| Cache Memory | |
| Installed Size: | 8 MB |
| Cache Per Processor: | 8 MB |
| RAM | |
| Installed Size: | 16 GB / 64 GB (max) |
| Technology: | DDR4 SDRAM - ECC |
| Effective Memory Speed: | 2133 MHz |
| Rated Memory Speed: | 2133 MHz |
| Form Factor: | DIMM 288-pin |
| Slots: | 4 (Total) / 3 (empty) |
| Features: | Unbuffered, dual channel memory architecture |
| Configuration Features: | 1 x 16 GB |
| Storage Controller | |
| Type: | RAID |
| Controller Interface Type: | SATA 6Gb/s |
| RAID Level: | RAID 0, RAID 1, RAID 5, RAID 10 |
| Optical Storage | |
| Type: | No optical drive |
| Monitor | |
| Monitor Type: | None. |
| Networking | |
| Ethernet Ports: | 2 x Gigabit Ethernet |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol: | IPMI 2.0 |
| Features: | Intel Remote Management Module Support |
| Expansion / Connectivity | |
| Bays: | 4 (total) / 4 (free) x hot-swap 2.5" / 3.5" shared ¦ 1 (total) / 1 (free) x internal |
| Slots: | 1 (total) / 0 (free) x CPU ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 ¦ 4 (total) / 3 (free) x DIMM 288-pin |
| Interfaces: | 9 x USB ¦ 8 x SATA ¦ 1 x serial ¦ 2 x LAN (Gigabit Ethernet) - RJ-45 ¦ 1 x VGA |
| Power | |
| Device Type: | Power supply |
| Installed Qty: | 1 |
| Power Provided: | 365 Watt |
| Manufacturer Warranty | |
| Service & Support: | Limited warranty - 3 years |
The technical details come from 3rd party. edgemo is not responsible for any errors.
