Printers & POSIntel Next Unit of Computing Kit 9 Extreme Compute Element - NUC9i5QNB - card Core i5 9300H 2.4 GHz - 0 GB - no HDD
SKU BKNUC9I5QNB
| Product Description: | Intel Next Unit of Computing Kit 9 Extreme Compute Element - NUC9i5QNB - card Core i5 9300H 2.4 GHz - 0 GB - no HDD |
| Type: | Personal computer - card |
| Processor: | Intel Core i5 (9th Gen) 9300H / 2.4 GHz (up to 4.1 GHz, (Quad-Core) |
| Processor Main Features: | Intel Virtualization Technology, Intel AES New Instructions |
| Cache Memory: | 8 MB |
| Cache Per Processor: | 8 MB |
| RAM: | 0 GB (installed) / 64 GB (max) - DDR4 SDRAM |
- Specifications
- Description
| General | |
| Type: | Personal computer |
| Product Form Factor: | Card |
| Embedded Security: | Trusted Platform Module (TPM) Security Chip |
| Processor / Chipset | |
| CPU: | Intel Core i5 (9th Gen) 9300H |
| Clock Speed: | 2.4 GHz |
| Max Turbo Speed: | 4.1 GHz |
| Number of Cores: | Quad-Core |
| CPU Qty: | 1 |
| Max CPU Qty: | 1 |
| Processor Main Features: | Intel Virtualization Technology, Intel AES New Instructions |
| Chipset Type: | Mobile Intel CM246 |
| Cache Memory | |
| Installed Size: | 8 MB |
| Cache Per Processor: | 8 MB |
| RAM | |
| Installed Size: | 0 GB (installed) / 64 GB (max) |
| Technology: | DDR4 SDRAM |
| Form Factor: | SO-DIMM 260-pin |
| Slots: | 2 (Total) / 2 (empty) |
| Features: | Dual channel memory architecture |
| Hard Drive | |
| Type: | No HDD |
| Storage Controller | |
| Type: | 1 x SATA/NVMe |
| Controller Interface Type: | SATA 6Gb/s / PCIe 3.0 x4 (NVMe) |
| RAID Level: | RAID 0, RAID 1 |
| Optical Storage | |
| Type: | No optical drive |
| Monitor | |
| Monitor Type: | None. |
| Graphics Controller | |
| Graphics Processor: | Intel UHD Graphics 630 |
| Video Interfaces: | HDMI, USB-C |
| Max Monitors Supported: | 3 |
| Audio Output | |
| Sound Output Mode: | 7.1 channel surround |
| Compliant Standards: | High Definition Audio |
| Networking | |
| Ethernet Ports: | 2 x Gigabit Ethernet |
| Ethernet Controller: | Intel I219-LM, I210-AT |
| Wireless LAN Supported: | Yes |
| Wireless NIC: | Intel Wi-Fi 6 AX 200 |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0, 802.11ax |
| Compliant Standards: | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0, IEEE 802.11ax, Wi-Fi CERTIFIED 6 |
| Expansion / Connectivity | |
| Slots: | 1 (total) / 1 (free) x M.2 Card - 2242/2280 (SATA/PCI Express x4 (NVMe)) ¦ 1 (total) / 1 (free) x M.2 Card - 2242/2280/22110 (SATA/PCI Express x4 (NVMe)) |
| Interfaces: | 4 x USB 3.1 Gen 2 - Type A (4 rear) ¦ 1 x HDMI ¦ 2 x LAN (Gigabit Ethernet) - RJ-45 ¦ 2 x Thunderbolt 3/USB-C 3.1 Gen 2 ¦ 1 x audio line-out - mini-jack / TOSLINK |
| Miscellaneous | |
| Compliant Standards: | CISPR 24, ICES-003, EN55024, FCC Part 15 B, FCC Part 15 C, AS/NZS 4268, FCC Part 15 E, BSMI CNS 13438, REACH, EN 62311, EN 300.440, China RoHS, EN 300 328, EN 301 489-1, KN32, KN35, AS/NZS 2772.2, EN 301 893, IEC/EN/UL 60950-1, EN 55032, EN 301 489-3, EU RoHS, IEC/EN/UL 62368-1, EN 301 489-17, ARPANSA, Taiwan BSMI RoHS, AS/NZS CISPR 32, VCCI 32 |
| Power | |
| Device Type: | No power supply |
| Manufacturer Warranty | |
| Service & Support: | Limited warranty - 3 years |
| Dimensions & Weight | |
| Width: | 20.3 cm |
| Depth: | 3.8 cm |
| Height: | 13.1 cm |
| Environmental Parameters | |
| Min Operating Temperature: | 0 °C |
| Max Operating Temperature: | 35 °C |
Intel NUC mini PCs squeeze a powerful processor, fast memory, and massive storage into a small form factor.
- Plug in Intel NUC and get to work
- Nothing to sacrifice but space
- Quality and reliability
The technical details come from 3rd party. edgemo is not responsible for any errors.
