Printers & POSIntel Next Unit of Computing Board 11 Pro Board NUC11TNBi30Z - motherboard - UCFF - Intel Core i3 1115G4
SKU BNUC11TNBI30Z00
| Product Description: | Intel Next Unit of Computing Board 11 Pro Board NUC11TNBi30Z - motherboard - UCFF - Intel Core i3 1115G4 |
| Product Type: | Motherboard - UCFF |
| Processor: | Intel Core i3 1115G4 (Dual-Core) |
| Processor Socket: | 1 |
| RAM Supported: | 2 SO-DIMM slots - DDR4, non-ECC |
| Storage Ports: | 1 x SATA-600, 2 x M.2 |
| USB / FireWire Ports: | 3 x USB 3.2 Gen 1 + 1 x USB 2.0 + (1 x USB 3.2 Gen 1 + 1 x USB 2.0 via headers) |
- Specifications
- Description
| General | |
| Product Type: | Motherboard - UCFF |
| Processor: | Intel Core i3 1115G4 (Dual-Core) |
| Cache Memory: | 6 MB |
| Max Processors Qty: | 1 |
| Supported RAM | |
| Technology: | DDR4 |
| Bus Clock: | 3200 MHz |
| Supported RAM Integrity Check: | Non-ECC |
| Graphics | |
| Graphics Controller: | Intel UHD Graphics |
| LAN | |
| Network Controller: | Intel I225-LM |
| Network Interfaces: | Gigabit Ethernet |
| Expansion / Connectivity | |
| Expansion Slots: | 2 x SO-DIMM 260-pin ¦ 1 x M.2 socket (2280 M.2 Key M slot) ¦ 1 x M.2 socket (2242 M.2 Key B slot) ¦ 1 x M.2 socket (2230 M.2 Key E slot) ¦ 1 x CPU |
| Storage Interfaces: | SATA-600 -connectors: 1 |
| Interfaces: | 3 x USB 3.2 Gen 1 ¦ 1 x USB 2.0 ¦ 2 x HDMI |
| Internal Interfaces: | 2 x USB 2.0 - header ¦ 1 x USB 3.2 Gen 1 |
Intel NUC motherboards come with a soldered processor. The motherboards enable fully customizable, scalable and configurable mini PCs for a wide variety of solutions.
The technical details come from 3rd party. edgemo is not responsible for any errors.
