Printers & POSIntel Next Unit of Computing 8 Rugged Board NUC8CCHBN - motherboard - 3.5" SBC - Intel Celeron N3350
SKU BKNUC8CCHBN
| Product Description: | Intel Next Unit of Computing 8 Rugged Board NUC8CCHBN - motherboard - 3.5" SBC - Intel Celeron N3350 |
| Product Type: | Motherboard - 3.5" SBC |
| Processor: | Intel Celeron N3350 / 1.1 GHz (Dual-Core) |
| Processor Socket: | 1 |
| RAM Installed: | 4 GB |
| Max RAM Size: | 4 GB |
| RAM Supported: | LPDDR3 |
- Specifications
- Description
| General | |
| Product Type: | Motherboard - 3.5" SBC |
| Processor: | Intel Celeron N3350 / 1.1 GHz (Dual-Core) |
| Cache Memory: | L2 - 2 MB |
| Max Processors Qty: | 1 |
| RAM Installed: | 4 GB |
| Supported RAM | |
| Max Size: | 4 GB |
| Technology: | LPDDR3 |
| Bus Clock: | 1866 MHz |
| Features: | Dual channel memory architecture |
| Graphics | |
| Graphics Controller: | Intel HD Graphics 500 |
| Audio | |
| Type: | HD Audio |
| LAN | |
| Network Controller: | Intel I211-AT |
| Network Interfaces: | Gigabit Ethernet |
| Expansion / Connectivity | |
| Expansion Slots: | 1 x M.2 socket (Key M) ¦ 1 x M.2 socket (Key E) ¦ 1 x CPU |
| Storage Interfaces: | PCIe 2.0 -connectors: 1 x M.2 |
| Interfaces: | 2 x USB 3.0 ¦ 2 x HDMI ¦ 1 x LAN (Gigabit Ethernet) |
| Internal Interfaces: | 2 x USB 2.0 ¦ 1 x USB 3.0 ¦ 1 x serial |
| Features | |
| BIOS Type: | Intel |
| Hardware Features: | 64GB eMMC onboard |
| Miscellaneous | |
| Width: | 10.16 cm |
| Depth: | 14.6 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Width: | 10.8 cm |
| Shipping Depth: | 15.4 cm |
| Shipping Height: | 3.2 cm |
| Manufacturer Warranty | |
| Service & Support: | Limited warranty - 3 years |
Intel NUC boards come with a soldered-on processor suited for fully customizable solutions.
The technical details come from 3rd party. edgemo is not responsible for any errors.
