Printers & POSIntel Next Unit of Computing 11 Extreme Compute Element - NUC11DBBi9 - card Core i9 11900KB 3.3 GHz - 0 GB - no HDD
SKU BNUC11DBBI90000
| Product Description: | Intel Next Unit of Computing 11 Extreme Compute Element - NUC11DBBi9 - card Core i9 11900KB 3.3 GHz - 0 GB - no HDD |
| Type: | Personal computer - card |
| Processor: | Intel Core i9 (11th Gen) 11900KB / 3.3 GHz (up to 4.9 GHz, (8-core) |
| Processor Main Features: | Intel Virtualization Technology, Intel AES New Instructions, Intel Platform Trust Technology (PTT) |
| Cache Memory: | 24 MB |
| Cache Per Processor: | 24 MB |
| RAM: | 0 GB (installed) / 64 GB (max) - DDR4 SDRAM |
- Specifications
- Description
| General | |
| Type: | Personal computer |
| Product Form Factor: | Card |
| Processor / Chipset | |
| CPU: | Intel Core i9 (11th Gen) 11900KB |
| Clock Speed: | 3.3 GHz |
| Max Turbo Speed: | 4.9 GHz |
| Number of Cores: | 8-core |
| CPU Qty: | 1 |
| Max CPU Qty: | 1 |
| Processor Main Features: | Intel Virtualization Technology, Intel AES New Instructions, Intel Platform Trust Technology (PTT) |
| Chipset Type: | Intel WM590 |
| Cache Memory | |
| Installed Size: | 24 MB |
| Cache Per Processor: | 24 MB |
| RAM | |
| Installed Size: | 0 GB (installed) / 64 GB (max) |
| Technology: | DDR4 SDRAM |
| Form Factor: | SO-DIMM 260-pin |
| Slots: | 2 (Total) / 2 (empty) |
| Hard Drive | |
| Type: | No HDD |
| Storage Controller | |
| Type: | 1 x SATA/NVMe |
| Controller Interface Type: | SATA 6Gb/s / PCIe 4.0 x4 (NVMe) |
| RAID Level: | RAID 0, RAID 1 |
| Optical Storage | |
| Type: | No optical drive |
| Monitor | |
| Monitor Type: | None. |
| Graphics Controller | |
| Interface Type: | Thunderbolt 4 / HDMI |
| Graphics Processor: | Intel UHD Graphics |
| Video Interfaces: | HDMI, USB-C |
| Max Monitors Supported: | 3 |
| Audio Output | |
| Sound Output Mode: | 7.1 channel surround |
| Compliant Standards: | High Definition Audio |
| Networking | |
| Ethernet Ports: | 2.5 Gigabit Ethernet |
| Ethernet Controller: | Intel I225-LM |
| Wireless LAN Supported: | Yes |
| Wireless NIC: | Intel Wi-Fi 6E AX 210 |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, 802.11ax, Bluetooth 5.2 |
| Compliant Standards: | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, Wi-Fi CERTIFIED 6, Bluetooth 5.2 |
| Expansion / Connectivity | |
| Slots: | 1 (total) / 1 (free) x M.2 Card - 2280 (PCIe 4.0 x4 mode) ¦ 2 (total) / 2 (free) x M.2 Card - 2242/2280 (SATA/PCIe 3.0 x4 (NVMe)) |
| Interfaces: | 2 x Thunderbolt 4/USB-C 3.2 Gen 2 ¦ 1 x HDMI ¦ 6 x USB 3.2 Gen 2 (6 rear) ¦ 1 x LAN (2.5Gigabit Ethernet) |
| Power | |
| Device Type: | No power supply |
| Manufacturer Warranty | |
| Service & Support: | Limited warranty - 3 years |
| Dimensions & Weight | |
| Width: | 3.9 cm |
| Depth: | 20.2 cm |
| Height: | 13.1 cm |
| Environmental Parameters | |
| Min Operating Temperature: | 0 °C |
| Max Operating Temperature: | 35 °C |
It's modular computing made easy. Intel NUC Elements give you a unique way to design and build integrated solutions and Mini PCs. Intel NUC Compute Elements, along with Intel NUC Board and Chassis Elements, deliver the flexibility of modular computing - so you can create the exact systems your customers want.
Whether you're building a custom system and only need compute, or a semi-custom or complete Mini PC solution, start with the Intel NUC Compute Element.
Whether you're building a custom system and only need compute, or a semi-custom or complete Mini PC solution, start with the Intel NUC Compute Element.
