Intel Ethernet Converged Network Adapter X710-DA4 - network adapter - PCIe 3.0 x8 - 10 Gigabit SFP+ x 4

SKU EX710DA4FHG1P5
Product Description:Intel Ethernet Converged Network Adapter X710-DA4 - network adapter - PCIe 3.0 x8 - 10 Gigabit SFP+ x 4
Device Type:Network adapter
Form Factor:Plug-in card
Interface (Bus) Type:PCI Express 3.0 x8
Ports:10 Gigabit SFP+ x 4
Dimensions (WxDxH):16.7 cm x 11.1 cm
Data Link Protocol:10GbE
Not in stock
Login for price
  • Specifications
  • Description
  • Accessories
General
Device Type:Network adapter
Form Factor:Plug-in card
Interface (Bus) Type:PCI Express 3.0 x8
Networking
Ports:10 Gigabit SFP+ x 4
Connectivity Technology:Wired
Data Link Protocol:10 Gigabit Ethernet
Data Transfer Rate:10 Gbps
Network / Transport Protocol:TCP/IP, UDP/IP, iSCSI
Remote Management Protocol:SNMP, RMON
Status Indicators:Port transmission speed, link/activity
Features:Flow control, VLAN support, packet filtering, IPv6 support, TCP/IP offloading, QoS, VMDq, IPv4 support, teaming support, PXE support, LSO, GSO, RSS, SR-IOV, DCB, ALB, Energy Efficient Ethernet, TSO, checksum offload support, MSI-X, UDP/IP offloading, WDT, FCoE support, iSCSI boot
Compliant Standards:IEEE 802.3, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1as, IEEE 802.1Qbg
Expansion / Connectivity
Interfaces:4 x 10Gb Ethernet - SFP+
Miscellaneous
Compliant Standards:FCC Class B certified, UL, VCCI, C-Tick, BSMI, RoHS, KCC, Directive 2011/65/EU, MSA SFF-8431
Software / System Requirements
OS Required:Microsoft Windows Server 2008 R2, Microsoft Windows Server 2008, Microsoft Windows Server 2008 R2 x64 Edition, Linux Kernel 2.6.32, Microsoft Windows Server 2012, FreeBSD 9, VMware ESXi 5.1, Microsoft Windows Server 2012 x64 Edition, Microsoft Windows Server 2012 R2, Linux Kernel 3.x, Microsoft Windows Server 2012 R2 x64 Edition, SuSE Linux Enterprise Server 11 SP3, Red Hat Enterprise Linux 6.5, VMware ESXi 5.5, FreeBSD 10, Red Hat Enterprise Linux 7, SuSE Linux Enterprise Server 11 SP3 x64 Edition, SUSE Linux Enterprise Server 12 x64 Edition
Dimensions & Weight
Depth:16.7 cm
Height:11.1 cm
Manufacturer Warranty
Service & Support:Limited warranty - lifetime
Environmental Parameters
Min Operating Temperature:0 °C
Max Operating Temperature:55 °C
vis mere
The X710 adapter family addresses the demanding needs of the next-generation agile data center by providing unmatched features for both server and network virtualization, flexibility for LAN and SAN networks and proven, reliable performance.
  • One adapter, one price
  • Network virtualization
  • Energy Efficient Ethernet (EEE)




The technical details come from 3rd party. edgemo is not responsible for any errors.
