Printers & POSIntel Ethernet Controller I210-AT - network adapter - PCIe 2.1 - Gigabit Ethernet x 1
SKU WGI210AT
| Product Description: | Intel Ethernet Controller I210-AT - network adapter - PCIe 2.1 - Gigabit Ethernet x 1 |
| Device Type: | Network adapter |
| Form Factor: | Plug-in card |
| Interface (Bus) Type: | PCI Express 2.1 x1 |
| Ports: | Gigabit Ethernet x 1 |
| Dimensions (WxDxH): | 9 mm x 9 mm |
| Cabling Type: | Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T |
- Specifications
- Description
| General | |
| Device Type: | Network adapter |
| Form Factor: | Plug-in card |
| Interface (Bus) Type: | PCI Express 2.1 x1 |
| Networking | |
| Ports: | Gigabit Ethernet x 1 |
| Connectivity Technology: | Wired |
| Cabling Type: | Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Data Transfer Rate: | 1 Gbps |
| Features: | Jumbo Frames support, Energy Efficient Ethernet |
| Compliant Standards: | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1as, IEEE 802.3az, IEEE 802.1Qav |
| Expansion / Connectivity | |
| Interfaces: | 1 x 1000Base-T |
| Miscellaneous | |
| Compliant Standards: | IEEE 1588 |
| Dimensions & Weight | |
| Width: | 9 mm |
| Depth: | 9 mm |
| Environmental Parameters | |
| Min Operating Temperature: | 0 °C |
| Max Operating Temperature: | 70 °C |
The technical details come from 3rd party. edgemo is not responsible for any errors.
