Printers & POSHP t740 - SFF - Ryzen Embedded V1756B 3.25 GHz - 8 GB - flash 32 GB
SKU 12H52EA#UUW
| Product Description: | HP t740 - SFF - Ryzen Embedded V1756B 3.25 GHz - 8 GB - flash 32 GB |
| Type: | Thin client - small form factor |
| Localisation: | Language: Danish, Norwegian, Finnish, Swedish / region: Denmark, Finland, Norway, Sweden |
| Processor: | 1 x AMD Ryzen Embedded V1756B / 3.25 GHz (3.6 GHz) (Quad-Core) |
| Processor Main Features: | AMD Memory Guard |
| Cache Memory: | 4 MB L3 Cache |
| Cache Per Processor: | 4 MB |
- Specifications
- Description
| General | |
| Type: | Thin client |
| Product Form Factor: | Small form factor |
| Built-in Devices: | Speaker |
| Embedded Security: | Trusted Platform Module (TPM 2.0) Security Chip |
| Localisation: | Language: Danish, Norwegian, Finnish, Swedish / region: Denmark, Finland, Norway, Sweden |
| Processor / Chipset | |
| CPU: | AMD Ryzen Embedded V1756B |
| Clock Speed: | 3.25 GHz |
| Max Turbo Speed: | 3.6 GHz |
| Number of Cores: | Quad-Core |
| CPU Qty: | 1 |
| Max CPU Qty: | 1 |
| L2 cache: | 2 MB |
| CPU Upgradability: | Not upgradable |
| Processor Main Features: | AMD Memory Guard |
| Cache Memory | |
| Installed Size: | L3 Cache - 4 MB |
| Cache Per Processor: | 4 MB |
| RAM | |
| Installed Size: | 8 GB / 32 GB (max) |
| Technology: | DDR4 SDRAM - non-ECC |
| Effective Memory Speed: | 2400 MHz |
| Rated Memory Speed: | 2400 MHz |
| Memory Specification Compliance: | PC4-19200 |
| Form Factor: | SO-DIMM 260-pin |
| Slots: | 2 (Total) / 0 (empty) |
| Features: | Dual channel memory architecture |
| Configuration Features: | 2 x 4 GB |
| Hard Drive | |
| Type: | Flash - M.2 |
| Capacity: | 1 x 32 GB |
| Features: | eMMC |
| Storage Controller | |
| Type: | SATA/NVMe |
| Channel Qty: | 2 |
| Optical Storage | |
| Type: | No optical drive |
| Monitor | |
| Monitor Type: | None. |
| Graphics Controller | |
| Graphics Processor: | AMD Radeon Vega 8 |
| Video Interfaces: | DisplayPort |
| Max Monitors Supported: | 4 |
| Audio Output | |
| Speakers Included: | 1 x mixed channel |
| Input Device | |
| Type: | Mouse, keyboard |
| Keyboard | |
| Keyboard Name: | HP Business Slim Keyboard |
| Interface: | USB |
| Mouse | |
| Technology: | Optical |
| Interface: | USB |
| Networking | |
| Ethernet Controller: | Realtek RTL8111EPH-CG |
| Wireless LAN Supported: | Yes |
| Wireless NIC: | Realtek RTL8852AE |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), Bluetooth 5.2 |
| Remote Management Protocol: | SNMP |
| Features: | Wake on LAN (WoL), PXE support, dual stream (2x2) |
| Compliant Standards: | IEEE 802.1p, IEEE 802.1x |
| Expansion / Connectivity | |
| Slots: | 1 (total) / 1 (free) x expansion slot ¦ 1 (total) / 1 (free) x PCIe ¦ 2 (total) / 0 (free) x M.2 Card |
| Interfaces: | 3 x USB 3.1 Gen 1 (1 front, 2 rear) ¦ 1 x USB 3.1 Gen 2 ¦ 1 x USB-C 3.1 Gen 2 ¦ 1 x headphones/microphone ¦ 4 x DisplayPort 1.2 ¦ 1 x LAN (Gigabit Ethernet) ¦ 2 x USB 2.0 |
| Miscellaneous | |
| Included Accessories: | Stand |
| Theft/Intrusion Protection: | Security lock slot (cable lock sold separately) |
| Security Slot Type: | Kensington security slot |
| VESA Mounting Interface: | 100 x 100 mm |
| Compliant Standards: | FCC Class B certified, UL, BSMI, GS, CB, CCC, FIPS 140-2, ICES Class B, WEEE, KCC Class B, AS/NZS, ERP, RoHS2, VCCI Class B, CISPR Class B, SEPA, low halogen, HP GSE, CNS |
| Power | |
| Device Type: | Power adapter |
| Voltage Required: | AC 115/230 V (50/60 Hz) |
| Power Provided: | 90 Watt |
| Operating System / Software | |
| OS Provided: | Windows 10 IoT Enterprise 2019 LTSB Value for Thin Clients 64-bit Edition |
| Software: | Microsoft Internet Explorer, Citrix ICA, Microsoft Windows Media Player, Microsoft Firewall, HP Remote Graphics Software, HP Device Manager, LogOn Manager, VMware Horizon View, Citrix HDX, HP ThinUpdate, HP Easy Shell, Microsoft SCCM/EDM-agent, HP USB Port Manager, HP Write Manager, Microsoft Unified Write Filter |
| Environmental Standards | |
| ENERGY STAR Certified: | Yes |
| Blue Angel Compliant: | Yes |
| Manufacturer Warranty | |
| Service & Support: | Limited warranty - parts and labour - 3 years |
| Dimensions & Weight | |
| Width: | 5 cm |
| Depth: | 21 cm |
| Height: | 21 cm |
| Weight: | 1.323 kg |
| Dimensions & Weight (Shipping) | |
| Shipping Weight: | 3.798 kg |
| Environmental Parameters | |
| Min Operating Temperature: | 10 °C |
| Max Operating Temperature: | 40 °C |
| Humidity Range Operating: | 10 - 90% (non-condensing) |
HP t740 Thin Client is built to drive graphics-intensive workflows on virtual and local computing environments, projecting to up to six 4K displays.
- Ultimate power & performance
- Robust security
- Modern flexibility
The technical details come from 3rd party. edgemo is not responsible for any errors.
