HP t540 - USFF - Ryzen Embedded R1305G 1.5 GHz - 4 GB - flash 32 GB

SKU 12H61EA#UUW
Product Description:HP t540 - USFF - Ryzen Embedded R1305G 1.5 GHz - 4 GB - flash 32 GB
Type:Thin client - ultra small form factor
Localisation:Language: Danish, Norwegian, Finnish, Swedish / region: Denmark, Finland, Norway, Sweden
Processor:1 x AMD Ryzen Embedded R1305G / 1.5 GHz (, up to 2.8 GHz, (Dual-Core)
Cache Memory:4 MB L3 Cache
Cache Per Processor:4 MB
RAM:4 GB (installed) / 16 GB (max) - DDR4 SDRAM
12-04-2024
  • Specifications
  • Description
General
Type:Thin client
Product Form Factor:Ultra small form factor
Embedded Security:Trusted Platform Module (TPM 2.0) Security Chip
Localisation:Language: Danish, Norwegian, Finnish, Swedish / region: Denmark, Finland, Norway, Sweden
Processor / Chipset
CPU:AMD Ryzen Embedded R1305G
Clock Speed:1.5 GHz
Max Turbo Speed:2.8 GHz
Number of Cores:Dual-Core
CPU Qty:1
Max CPU Qty:1
CPU Upgradability:Not upgradable
Cache Memory
Installed Size:L3 Cache - 4 MB
Cache Per Processor:4 MB
RAM
Installed Size:4 GB / 16 GB (max)
Technology:DDR4 SDRAM
Effective Memory Speed:2400 MHz
Rated Memory Speed:2400 MHz
Form Factor:SO-DIMM 260-pin
Slots:1 (Total) / 0 (empty)
Configuration Features:1 x 4 GB
Hard Drive
Type:Flash - M.2
Capacity:1 x 32 GB
Features:eMMC
Optical Storage
Type:No optical drive
Monitor
Monitor Type:None.
Graphics Controller
Graphics Processor:AMD Radeon Vega 3
Video Interfaces:DisplayPort
Max Monitors Supported:2
Input Device
Type:Mouse, keyboard
Keyboard
Keyboard Name:HP USB Business Slim Keyboard
Interface:USB
Mouse
Technology:Optical
Interface:USB
Networking
Ethernet Controller:Realtek RTL8111HSH
Wireless LAN Supported:Yes
Wireless NIC:Realtek RTL8852AE
Data Link Protocol:Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.2, IEEE 802.11ax (Wi-Fi 6)
Expansion / Connectivity
Slots:1 (total) / 0 (free) x M.2 Card (for internal storage)
Interfaces:3 x USB 3.1 Gen 1 (1 front, 2 rear) ¦ 1 x USB-C 3.1 Gen 1 (1 in front) ¦ 2 x USB 2.0 (2 rear) ¦ Headphones/microphone (1 in front) ¦ 2 x DisplayPort 1.2 ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x serial (powered)
Miscellaneous
Theft/Intrusion Protection:Security lock slot (cable lock sold separately)
Security Slot Type:Kensington security slot
Compliant Standards:FCC Class B certified, UL, BSMI, GS, CB, CCC, ICES Class B, WEEE, KCC Class B, AS/NZS, ERP, RoHS2, VCCI Class B, CP65, CISPR Class B, SEPA, low halogen, HP GSE, EN, CNS, IEEE 1680.1
Power
Device Type:Power adapter
Power Device Name:HP Smart AC Adapter
Voltage Required:AC 120/230 V (50/60 Hz)
Power Provided:45 Watt
Operating System / Software
OS Provided:IGEL OS
Sustainability Information
ENERGY STAR Certified:Yes
Manufacturer Warranty
Service & Support:Limited warranty - parts and labour - 3 years
Dimensions & Weight
Width:3.5 cm
Depth:20 cm
Height:20 cm
Environmental Parameters
Min Operating Temperature:10 °C
Max Operating Temperature:40 °C
Humidity Range Operating:10 - 90% (non-condensing)
vis mere
Transition your fleet to the cloud with the HP t540 thin client. Support your computing needs with versatile configurations and component-level security.
  • Designed for your organization's computing needs
  • Neutralize threats and keep data safe and secure
  • High performance
  • Dual UHD/4K display support




The technical details come from 3rd party. edgemo is not responsible for any errors.
