HP Elite t655 - SFF - Ryzen Embedded R2314 2.1 GHz - 8 GB - flash 32 GB

SKU 5H0W5EA#UUW

Product Description:	HP Elite t655 - SFF - Ryzen Embedded R2314 2.1 GHz - 8 GB - flash 32 GB
Type:	Thin client - small form factor
Localisation:	Language: Danish, Norwegian, Finnish, Swedish / region: Denmark, Finland, Norway, Sweden
Processor:	1 x AMD Ryzen Embedded R2314 / 2.1 GHz (, up to 3.5 GHz, (Quad-Core)
Cache Memory:	2 MB L3 Cache
Cache Per Processor:	2 MB
RAM:	8 GB (installed) / 32 GB (max) - DDR4 SDRAM

21-05-2024

Specifications
Description
Accessories

General
Type:	Thin client
Product Form Factor:	Small form factor
Embedded Security:	Trusted Platform Module (TPM 2.0) Security Chip
Localisation:	Language: Danish, Norwegian, Finnish, Swedish / region: Denmark, Finland, Norway, Sweden

Processor / Chipset
CPU:	AMD Ryzen Embedded R2314
Clock Speed:	2.1 GHz
Max Turbo Speed:	3.5 GHz
Number of Cores:	Quad-Core
CPU Qty:	1
Max CPU Qty:	1
CPU Upgradability:	Not upgradable

Cache Memory
Installed Size:	L3 Cache - 2 MB
Cache Per Processor:	2 MB

RAM
Installed Size:	8 GB / 32 GB (max)
Technology:	DDR4 SDRAM
Effective Memory Speed:	2667 MHz
Rated Memory Speed:	3200 MHz
Form Factor:	SO-DIMM 260-pin
Slots:	2 (Total) / 0 (empty)
Configuration Features:	2 x 4 GB

Hard Drive
Type:	Flash - M.2
Capacity:	1 x 32 GB
Features:	eMMC

Optical Storage
Type:	No optical drive

Monitor
Monitor Type:	None.

Graphics Controller
Graphics Processor:	AMD Radeon Graphics
Video Interfaces:	DisplayPort
Max Monitors Supported:	3

Audio Output
Sound Output Mode:	Stereo

Input Device
Type:	Mouse, keyboard

Keyboard
Interface:	USB

Mouse
Interface:	USB

Networking
Ethernet Controller:	Realtek RTL8111EPH-CG
Wireless LAN Supported:	Yes
Wireless NIC:	Realtek RTL8852BE
Data Link Protocol:	Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.2, IEEE 802.11ax (Wi-Fi 6)
Features:	Dual stream (2x2)

Expansion / Connectivity
Slots:	1 (total) / 0 (free) x M.2 Card (for internal storage)
Interfaces:	2 x USB 3.1 Gen 1 (2 front) ¦ 3 x USB-C 3.2 Gen 2 (1 front, 2 rear) ¦ 1 x audio line-out/line-in - mini-jack (1 front) ¦ 3 x DisplayPort 1.2 (3 rear) ¦ 2 x USB 3.2 Gen 1 (2 rear) ¦ 1 x LAN (Gigabit Ethernet) (1 rear) ¦ 1 x audio line-out/headphones (1 rear)

Miscellaneous
Theft/Intrusion Protection:	Security lock slot (cable lock sold separately)
VESA Mounting Interface:	100 x 100 mm, VESA
Compliant Standards:	WEEE, EN 60601-1-2, ERP, CECP, RoHS2, SEPA, low halogen, EMV, HP GSE

Power
Device Type:	Power adapter
Power Device Name:	HP Smart AC Adapter
Voltage Required:	AC 100-240 V (50/60 Hz)
Power Provided:	45 Watt

Operating System / Software
OS Provided:	HP ThinPro Danish / English / Finnish / Norwegian / Swedish
Software:	Mozilla Firefox, HP Easy Tools, HP Device Manager, HP ThinUpdate, HP True Graphics, HP Easy Shell, HP Write Manager, HP Cloud Endpoint Manager, Microsoft Azure Virtual Desktop

Sustainability Information
ENERGY STAR Certified:	Yes

Manufacturer Warranty
Service & Support:	Limited warranty - parts and labour - 1 year

Dimensions & Weight
Dimensions & Weight Details:	3.5 cm - 20 cm - 20 cm - 1.174 kg - with stand ¦ - 1.12 kg - without stand
Width:	3.5 cm
Depth:	20 cm
Height:	20 cm
Weight:	1.174 kg

Dimensions & Weight (Shipping)
Shipping Weight:	2.106 kg

Environmental Parameters
Min Operating Temperature:	10 °C
Max Operating Temperature:	40 °C
Humidity Range Operating:	10 - 90% (non-condensing)
