HP Elite 800 G9 - SFF Core i5 13500 2.5 GHz - 16 GB - SSD 256 GB

SKU 628B7ET#UUW

Product Description:	HP Elite 800 G9 - SFF Core i5 13500 2.5 GHz - 16 GB - SSD 256 GB
Type:	Personal computer - SFF
Bundled Services:	HP 3 years Next Business Day Onsite Hardware Support
Localisation:	Language: Danish, Norwegian, Finnish, Swedish / region: Denmark, Finland, Norway, Sweden
Processor:	Intel Core i5 (13th Gen) 13500 / 2.5 GHz (up to 4.8 GHz, (14-core)
Processor Main Features:	Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache
Cache Memory:	24 MB L3 Cache

In Stock(100)

Specifications
Description
Accessories

General
Type:	Personal computer
Bundled Services:	HP 3 years Next Business Day Onsite Hardware Support
Product Form Factor:	SFF
Sensors:	HP Tamper Lock
Embedded Security:	Trusted Platform Module (TPM 2.0) Security Chip
Localisation:	Language: Danish, Norwegian, Finnish, Swedish / region: Denmark, Finland, Norway, Sweden

Processor / Chipset
CPU:	Intel Core i5 (13th Gen) 13500
Clock Speed:	2.5 GHz (P-core) / 1.8 GHz (E-core)
Max Turbo Speed:	4.8 GHz (P-core) / 3.5 GHz (E-core)
Number of Cores:	14-core
CPU Qty:	1
Max CPU Qty:	1
L2 cache:	11.5 MB
CPU Upgradability:	Upgradable
Processor Main Features:	Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache
Chipset Type:	Intel Q670

Cache Memory
Installed Size:	L3 Cache - 24 MB
Cache Per Processor:	24 MB

RAM
Installed Size:	16 GB (installed) / 128 GB (max)
Technology:	DDR5 SDRAM
Effective Memory Speed:	4800 MHz
Rated Memory Speed:	4800 MHz
Form Factor:	DIMM 288-pin
Slots:	4 (Total) / 2 (empty)
Features:	Unbuffered
Configuration Features:	2 x 8 GB

Hard Drive
Type:	SSD - M.2 2280
Capacity:	1 x 256 GB
Interface Type:	PCI Express
Features:	NVM Express (NVMe)

Storage Controller
Type:	1 x SATA/NVMe
Controller Interface Type:	SATA-600 / NVMe
Channel Qty:	4

Optical Storage
Type:	No optical drive

Monitor
Monitor Type:	None.

Graphics Controller
Graphics Processor:	Intel UHD Graphics 770 Dynamic Video Memory Technology
Video Interfaces:	HDMI, DisplayPort
HDCP Compatible:	Yes

Audio Output
Sound Output Mode:	Stereo
Max Sampling Rate:	192 kHz
Compliant Standards:	High Definition Audio

Networking
Interface (Bus) Type:	PCI Express Mini Card (M.2)
Ethernet Controller:	Intel I219-LM
Wireless LAN Supported:	Yes
Wireless NIC:	Intel Wi-Fi 6E AX 211
Data Link Protocol:	Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3
Remote Management Protocol:	SNMP 2
Features:	Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support, dual stream (2x2)
Compliant Standards:	IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.1x, IEEE 802.11i, Wi-Fi CERTIFIED, IEEE 802.11h, IEEE 802.11k, IEEE 802.3az, IEEE 802.11r, IEEE 802.11v

Expansion / Connectivity
Bays:	1 (total) / 1 (free) x external 5.25" Slim Line ¦ 2 (total) / 2 (free) x internal 3.5"
Slots:	1 (total) / 1 (free) x PCIe 4.0 x16 ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 (x4 mode) ¦ 2 (total) / 2 (free) x PCIe 3.0 x1 ¦ 1 (total) / 0 (free) x M.2 Card - 2230 (for wireless module) ¦ 2 (total) / 1 (free) x M.2 Card - 2280 (for internal storage)
Interfaces:	3 x USB 2.0 ¦ 3 x USB 3.2 Gen 1 (one of them is fast-charging) ¦ 4 x USB 3.2 Gen 2 (4 in front) ¦ 1 x USB-C 3.2 Gen 2x2 ¦ 2 x DisplayPort 1.4a ¦ 1 x headphones/microphone (1 in front) (CTIA and OMTP headset support) ¦ 1 x audio line-out/line-in (1 rear) ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x HDMI

Miscellaneous
Theft/Intrusion Protection:	Security lock slot (cable lock sold separately), padlock loop
Security Slot Type:	Kensington security slot
Compliant Standards:	Low halogen
Manufacturer Selling Program:	HP Smart Buy

Power
Device Type:	Power supply
Voltage Required:	AC 90-264 V (50/60 Hz)
80 PLUS Certification:	80 PLUS Platinum
Power Factor Correction:	Yes (active)

Operating System / Software
OS Provided:	Windows 11 Pro Danish / English / Finnish / Norwegian / Swedish
Software:	HP Support Assistant, HP PC Hardware Diagnostics UEFI, Microsoft 365 (Trial), HP Secure Erase, HP Setup Integrated OOBE, HP Notifications, HP Connection Optimizer, HP Sure Click, HP Privacy Settings, HP Cloud Recovery, HP Sure Sense, HP Sure Admin, HP QuickDrop, HP BIOSphere Gen6, HP DriveLock, myHP, HP Desktop Support Utilities, HP Tamper Lock, HP Client Security Manager Gen7, HP Easy Clean, HP Sure Recover Gen5, HP Sure Sense Gen2, HP Sure Run Gen5, HP Sure Start Gen7

Sustainability Information
ENERGY STAR Certified:	Yes

Manufacturer Warranty
Service & Support:	Limited warranty - 3 years - on-site

Dimensions & Weight
Width:	33.8 cm
Depth:	30.8 cm
Height:	10 cm
Weight:	5.4 kg

Dimensions & Weight (Shipping)
Shipping Width:	39.9 cm
Shipping Depth:	49.9 cm
Shipping Height:	23 cm
Shipping Weight:	7.92 kg

Environmental Parameters
Min Operating Temperature:	10 °C
Max Operating Temperature:	35 °C
Humidity Range Operating:	10 - 90% RH (non-condensing)

vis mere

The HP Elite 800 G9 presents a reliable and powerful personal computer designed to cater to diverse performance needs. Featuring an Intel Core i5 processor and DDR5 SDRAM technology, this system ensures smooth multitasking for everyday applications. With a single high-speed NVMe SSD as the storage option, fast data access enhances productivity. Its advanced audio output, designed to support high definition audio and a maximum sampling rate of 192 kHz, ensures an immersive experience for media consumption and communication. Equipped with various ports including USB 3.2 Gen 2 and USB-C 3.2 Gen 2x2, along with DisplayPort 1.4a, the system offers versatile connectivity options for external devices and displays.

Intel Core i5 processor for efficient performance
Fast NVMe SSD for quick data access
High definition audio output for enhanced sound quality
Multiple connectivity options including USB and DisplayPort
Robust DDR5 RAM technology for improved multitasking

The technical details come from 3rd party. edgemo is not responsible for any errors.
