Printers & POSHoneywell MS5145 Eclipse - barcode scanner
SKU MK5145-31A38-EU
| Product Description: | Honeywell MS5145 Eclipse - barcode scanner |
| Type: | Barcode scanner - handheld - USB - decoded |
| Colour: | Black |
| Localisation: | Europe |
| Minimum Bar Width: | 4 mil |
| Scan Field Width: | 49 mm - 195 mm |
| Scan Element Type: | Visible laser diode |
- Specifications
- Description
| General | |
| Type: | Barcode scanner - handheld |
| Colour: | Black |
| Localisation: | Europe |
| Barcode | |
| Interface Type: | USB |
| Minimum Bar Width: | 4 mil |
| Scan Field Width: | 49 mm - 195 mm |
| Scan Element Type: | Visible laser diode |
| Light Source Wave Length: | 650 nm |
| Scan Mode: | Single-pass |
| Scan Speed: | 72 line / sec |
| Max Working Distance: | 191 mm |
| Skew (Degrees): | 52 |
| Pitch (Degrees): | 68 |
| Print Contrast Signal (PCS): | 35% |
| Decode Capability: | Code 93, Matrix 2 of 5, Code 39, UCC/EAN-128, GS1 DataBar, Telepen, Code 39 Full ASCII, EAN/JAN-8, EAN/JAN-13, UPC-A, UPC-E, Codabar, Code 128, Code 11, Interleaved 2 of 5, MSI-Plessey |
| TTL Decoding: | Decoded |
| Connectivity Technology: | Wired |
| OK Notification: | Beeper, LED indicator |
| Features: | Triggered |
| Expansion / Connectivity | |
| Interfaces: | 1 x USB - Type A |
| Miscellaneous | |
| Compliant Standards: | FCC Class B certified, UL, IEC 825-1/EN 60825-1 class 1, EN55022 Class B, ICES-003 Class B |
| Power | |
| Power Device: | Power adapter - external |
| Dimensions & Weight | |
| Width: | 6.3 cm |
| Depth: | 16.9 cm |
| Height: | 3.5 cm |
| Weight: | 97 g |
| Environmental Parameters | |
| Min Operating Temperature: | 0 °C |
| Max Operating Temperature: | 40 °C |
| Humidity Range Operating: | 5 - 95% |
| Drop Specification: | 1.5 m |
Honeywell's MS5145 Eclipse is a low cost laser-based alternative to CCD scanners. Its compact form factor and high end feature set simplify its use in a variety of applications at the press of a button.
Eclipse is a single-line, hand-held laser scanner. Equipped with Honeywell's patented CodeGate technology, Eclipse can be used in a wide variety of applications. CodeGate technology allows the user to easily target the desired bar code and complete data transmission with the press of a single button. This makes Eclipse a perfect selection for menu scanning, point-of-sale, document processing and inventory control.
With Honeywell's state-of-the-art scanning technology, the MS5145 Eclipse has a longer working range and a wider scan field than a typical CCD. The width of the scan line grows as the scanner moves further away from bar codes.
CodeSense is a unique feature employed by Eclipse in the absence of infrared object detection. It provides the user with a pulsing laser line for bar code detection. When a bar code is detected, the laser line switches to a constant state to allow for scanning via CodeGate.
Eclipse is a single-line, hand-held laser scanner. Equipped with Honeywell's patented CodeGate technology, Eclipse can be used in a wide variety of applications. CodeGate technology allows the user to easily target the desired bar code and complete data transmission with the press of a single button. This makes Eclipse a perfect selection for menu scanning, point-of-sale, document processing and inventory control.
With Honeywell's state-of-the-art scanning technology, the MS5145 Eclipse has a longer working range and a wider scan field than a typical CCD. The width of the scan line grows as the scanner moves further away from bar codes.
CodeSense is a unique feature employed by Eclipse in the absence of infrared object detection. It provides the user with a pulsing laser line for bar code detection. When a bar code is detected, the laser line switches to a constant state to allow for scanning via CodeGate.
- CodeGate
- CodeSense
- Powerlink cables
- Flash ROM
