Datamax DMXNet II - print server

SKU OPT78-2724-15
Product Description:Datamax DMXNet II - print server
Device Type:Print server
Form Factor:Plug-in module
Data Link Protocol:10Mb LAN, 802.11b/g
Designed For:M-Class Mark II M-4206, M-4210, M-4308
In Stock(5)
  • Specifications
  • Description
General
Device Type:Print server
Form Factor:Plug-in module
Networking
Connectivity Technology:Wireless, wired
Data Link Protocol:Ethernet, IEEE 802.11b, IEEE 802.11g
Expansion / Connectivity
Interfaces:1 x Ethernet - RJ-45
Compatible Slots:1 x Expansion Slot
Compatibility Information
Designed For:Datamax M-Class Mark II M-4206, M-4210, M-4308
vis mere
DMXNet is a high-performance network interface card for the Datamax I-Class, A-Class, and WClass Printer families. Driven by a powerful 32-bit RISC NET+ARM processor, the DMXNet card is easily installed and configured within seconds from the front panel or remotely via any standard Web browser to bring the levels of product maintenance and support through enhanced monitoring and control.
The DMXNet card supports basic IPX (Novell) and IP protocols over various Ethernet frame types. All protocols may be enabled and are supported concurrently. Multiple management connections, including network services APIs where provided, may be active at the same time. NetWare is operable in Network Directory Services and in Novell bindery or bindery emulation modes. IPX/SPX is used to support printer status requests so that the NIC is compatible with both Novell Pconsole and Net Admin utilities. The NIC includes an SNMP agent operating over IPX.
The NIC includes an SNMP V1 agent and implements the RFC1213 groups of MIB II as well as Host Resource MIB, the Printer MIB, and a DMX Enterprise Private MIB. The NIC MIB and Private MIB provide access to essentially the same NIC setup and Printer setup parameters as the web pages. The NIC supports one basic trap destination IP address for general trap messages. Current traps include general printer fault, head up, paper out, and ribbon out.
  • Internet printing protocol
  • Embedded web server
  • Remote printer management
  • DMX configuration utility




The technical details come from 3rd party. edgemo is not responsible for any errors.
