HPE SR932i-p Gen11 SPDM - storage controller - support for 32 drives without expander, 238 drives with expander - SATA 6Gb/s / SAS 24Gb/s / PCIe 4.0 (NVMe) - PCIe 4.0 x16
SKU P47184-B21
Product Description: | HPE SR932i-p Gen11 SPDM - storage controller - support for 32 drives without expander, 238 drives with expander - SATA 6Gb/s / SAS 24Gb/s / PCIe 4.0 (NVMe) - PCIe 4.0 x16 |
Device Type: | Storage controller - plug-in card |
Bus Type: | PCIe 4.0 x16 |
Interface: | SATA 6Gb/s / SAS 24Gb/s / PCIe 4.0 (NVMe) |
Buffer Size: | 8 GB |
Supported Devices: | Disk array (RAID), solid state drive |
Channel Qty: | 32 |
- Specifications
- Description
General | |
Device Type: | Storage controller - plug-in card |
Host Bus: | PCIe 4.0 x16 |
Storage Controller | |
Interface: | SATA 6Gb/s / SAS 24Gb/s / PCIe 4.0 (NVMe) |
Buffer Size: | 8 GB |
Supported Devices: | Disk array (RAID), solid state drive |
Channel Qty: | 32 |
RAID Level: | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID 1T, RAID 10T |
Processor: | Microchip Technology SmartROC 3200pe |
Expansion / Connectivity | |
Interfaces: | 4 x SATA 6Gb/s / SAS 24Gb/s / PCIe 4.0 (NVMe) - Slim SAS x8 |
Connections: | 1 x PCIe 4.0 x16 |
Miscellaneous | |
Features: | SecureBoot, Hardware Root of Trust, Bootable RAID Array support, Flash Backed Write Cache (FBWC), full-height, half-length, read ahead caching, write-back caching, mixed mode (RAID & HBA), SED key management, Security Protection Data Model (SPDM), SMART Predictive Drive Failure |
Software / System Requirements | |
Software Included: | UEFI System Utilities (storage configuration), HPE Smart Storage Administrator (SSA), Smart Storage Administrator Command Line Interface (SSA CLI) |
OS Required: | SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, Ubuntu, VMware ESXi |
Manufacturer Warranty | |
Service & Support: | Limited warranty - parts - 3 years |
Does your data center need increased storage, protection, flexibility, and performance for today's applications demands? HPE Compute SR 900 Series Gen11 Controller supports 24Gb/s SAS and PCIe 4.0 for increased performance while supporting advanced RAID levels with 8 GB flash-backed write cache (FBWC). This tri-mode (SAS/SATA/NVMe) controller operates in mixed mode which combines RAID and HBA operations simultaneously, giving you improved deployment flexibility. The HPE Compute SR932i-p Gen11 Controller provides the ability to support internally attached drives, allowing integration with existing hardware. This controller also features HPE SR Secure Encryption for data-at-rest using controller-based Encryption(CBE) for SAS, SATA and NVMe devices which improves reliability. The Gen11 features Hardware Root of Trust, and Security Protection Data Model (SPDM) support.
- The HPE Compute SR Gen11 Controllers feature up to 46GB/s bi-directional throughput and up to 3.5 million IOPS.
- HPE Compute SR Gen11 Controllers support all major OS’s including but not limited to Windows, Linux®, and VMware®; full tool suite including command line interface, web-based management, and out-of-band management support.
