Printers & POSHPE MR216i-p Gen11 SPDM - storage controller - up to 240 physical drives, up to 64 logical drives - SATA 6Gb/s / SAS 12Gb/s / PCIe 4.0 (NVMe) - PCIe 4.0 x8
SKU P47785-B21
| Product Description: | HPE MR216i-p Gen11 SPDM - storage controller - up to 240 physical drives, up to 64 logical drives - SATA 6Gb/s / SAS 12Gb/s / PCIe 4.0 (NVMe) - PCIe 4.0 x8 |
| Device Type: | Storage controller - plug-in card |
| Bus Type: | PCIe 4.0 x8 |
| Interface: | SATA 6Gb/s / SAS 12Gb/s / PCIe 4.0 (NVMe) |
| Supported Devices: | Disk array (RAID), solid state drive |
| Channel Qty: | 16 |
| RAID Level: | RAID 0, RAID 1, RAID 10 |
- Specifications
- Description
| General | |
| Device Type: | Storage controller - plug-in card |
| Host Bus: | PCIe 4.0 x8 |
| Storage Controller | |
| Interface: | SATA 6Gb/s / SAS 12Gb/s / PCIe 4.0 (NVMe) |
| Supported Devices: | Disk array (RAID), solid state drive |
| Channel Qty: | 16 |
| RAID Level: | RAID 0, RAID 1, RAID 10 |
| Processor: | Broadcom SAS3916 |
| Expansion / Connectivity | |
| Interfaces: | SATA 6Gb/s / SAS 12Gb/s / PCIe 4.0 (NVMe) - Slim SAS x8 |
| Connections: | 1 x PCIe 4.0 x8 |
| Miscellaneous | |
| Features: | Load Balancing, Online Capacity Expansion (OCE), Hardware Root of Trust, S.M.A.R.T. support, read ahead caching, write-back caching, configurable stripe size up to 1 MB, global and dedicated hot spare with revertible hot, Universal Backplane Management (UBM) ready, mixed mode (RAID & HBA), Legacy and UEFI boot mode, rebuild, SED key management, without Cache, Security Protection Data Model (SPDM) |
| Software / System Requirements | |
| Software Included: | StorCLI, UEFI System Utilities (storage configuration), MegaRAID Storage Administrator |
| OS Required: | SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, CentOS, Ubuntu, VMware ESXi |
| Manufacturer Warranty | |
| Service & Support: | Limited warranty - parts - 3 years |
Do you need a versatile, simplified, and flexible choice for your data centers? HPE Compute MR Gen11 Controllers are expansive and agile PCIe Gen4.0 storage controllers based on Broadcom MegaRAID technology that deliver quality, performance, and security for mission-critical applications. The HPE MR416i-o / HPE MR416i-p Gen11 Controllers are ideal for all data center environments where RAID is applicable offering reduced rebuild times, high-bandwidth, and 240K RAID5 Random Write IOPS. The HPE MR416i-o / HPE MR416i-p Gen11 Controllers are ideal for all virtualized environments where HBA / pass-through mode is applicable offering high bandwidth and 3 million Random Write IOPS. HPE Compute MR Gen11 Controllers offer solutions for multiple workflows across multiple applications to deliver customer satisfaction.
- HPE Compute MR Gen11 Controllers offer up to 13.7GBs of bandwidth, and 8 PCIe Gen4.0 host lanes.
- HPE Compute MR Gen11 Controllers are built with the HPE Silicon Root of Trust for firmware authentication and support for self-encrypting drives to help protect data at rest and prevent of malware.
- HPE Compute MR Gen11 Controllers support full tool suite including command line interface, web-based management, and out-of-band management support.
The technical details come from 3rd party. edgemo is not responsible for any errors.
