HPE MegaRAID 416i-a - storage controller (RAID) - SATA 6Gb/s / SAS 12Gb/s / PCIe 4.0 (NVMe) - PCIe 4.0 x8

Does your data center, cloud, or high-performance computing (HPC) environment require increased storage capacity protection, flexibility, and performance for today's application demands? Data center, cloud, and HPC environments require large amounts of storage capacity, that provide the protection, flexibility, and performance that today's applications demand. HPE MR Gen10 Plus Controllers offer 12Gb/s SAS / SATA / PCIe (NVMe) Gen4 Tri-Mode support with 16 and 8 internal ports to address the needs by delivering more performance and RAID data protection for high-end server storage applications. These controllers are the first RAID adapters to offer PCIe Gen4 host and PCIe Gen4 storage interfaces which enables high bandwidth and more IOPS. Also, the Tri-Mode SerDes technology enables operation of NVMe, SAS, or SATA devices in a single drive bay operating in all modes concurrently, seamlessly negotiating between speeds and protocols.

• HPE MR Gen10 Plus Controllers feature the MR416i-a Gen10 Plus, MR416i-p Gen10 Plus, MR216i-a Gen10 Plus, and MR216i-p Gen10 Plus controllers with impressive performance, including up to 13,700 Mbs of bandwidth, 3 million random read IOPS, and 240K RAID5 random write IOPS.
• HPE MR Gen10 Plus Controllers are enabled with SerDes for exceptional support of NVMe4/SAS3/SATA protocols.
• HPE MR Gen10 Plus Controllers are built with the Silicon Root of Trust from HPE for firmware authentication and support for self-encrypting drives to help ensure protection for data at rest and prevention of malware.
• HPE MR Gen10 Plus Storage Controllers support all major OS’s including but not limited to Windows, Linux®, and VMware®; full tool suite, including command line interface, web-based management, and out-of-band management support.
