HPE Aruba USB LTE Modem - wireless cellular modem - 4G LTE

SKU R8F34A
Product Description:HPE Aruba USB LTE Modem - wireless cellular modem - 4G LTE
Device Type:Wireless cellular modem - USB
Form Factor:External
Max Transfer Rate:480 Mbps
Mobile Communication Protocol:FDD LTE, TDD LTE, WCDMA
Mobile Band:LTE B1/B2/B3/B4/B5/B7/B8/B9/B12/B13/B14/B17/B18/B19/B20/B21/B25/B26/B28/B29/B30/B32/B38/B39/B40/B41/B66 / WCDMA B1/B2/B3/B4/B5/B8/B9/B19
Dimensions (WxDxH):5 cm x 10 cm x 2 cm
18-08-2025
  • Specifications
  • Description
General
Device Type:Wireless cellular modem
Form Factor:External
Built-in Devices:Beidou, GPS / GLONASS / Galileo, QZSS
Modem
Bus:USB
Connectivity Technology:Wireless
Max Transfer Rate:480 Mbps
Mobile Band:LTE B1/B2/B3/B4/B5/B7/B8/B9/B12/B13/B14/B17/B18/B19/B20/B21/B25/B26/B28/B29/B30/B32/B38/B39/B40/B41/B66 / WCDMA B1/B2/B3/B4/B5/B8/B9/B19
Mobile Communication Protocol:FDD LTE, TDD LTE, WCDMA
Antenna:Internal
Antenna Qty:2
Features:270° horizontal swivel / 90° vertical swivel
Expansion / Connectivity
Interfaces:1 x USB 2.0 - Type A
Miscellaneous
SIM Card Supported:Micro-SIM x 1
Compliant Standards:Plug and Play, UL 60950, IEC 60950, EN 60950, EN 62368-1, IEC 62368-1
Power
Power Consumption Operational:3.5 Watt
Dimensions & Weight
Width:5 cm
Depth:10 cm
Height:2 cm
Weight:78 g
Environmental Parameters
Min Operating Temperature:0 °C
Max Operating Temperature:40 °C
Humidity Range Operating:10 - 90% (non-condensing)
vis mere
The HPE Aruba USB LTE Modem is an external wireless cellular modem designed to offer reliable Internet connectivity for a wide range of applications. With its internal dual-antenna setup, it ensures strong and stable signal reception, suitable for users in varied environments. The modem's unique swivel design allows for flexible positioning, ensuring optimal signal strength.
In addition to its robust connectivity features, the modem supports a variety of navigation systems, including GPS, Galileo, and Beidou, providing precise location tracking capabilities. It is compatible with 4G LTE networks, offering high-speed data transfer rates of up to 480 Mbps, suitable for demanding online activities. Furthermore, the HPE Aruba USB LTE Modem is built to last, with compliance to multiple international safety standards and designed to operate across a wide range of environmental conditions. This makes it a reliable choice for users looking for a durable and efficient Internet connectivity solution.
  • Internal dual-antenna design for reliable signal reception
  • 270° horizontal and 90° vertical swivel for optimal positioning
  • Supports multiple navigation systems including GPS and Galileo
  • 4G LTE connectivity with up to 480 Mbps transfer rate
  • Meets global safety and operational standards
