HPE Aruba 3810M 16SFP+ 2-slot Switch - switch - 16 ports - Managed - rack-mountable

SKU JL075A
Product Description:HPE Aruba 3810M 16SFP+ 2-slot Switch - switch - 16 ports - Managed - rack-mountable
Device Type:Switch - 16 ports - L3 - Managed - stackable
Enclosure Type:Rack-mountable 1U
Subtype:10 Gigabit Ethernet
Ports:16 x 10 Gigabit SFP+
Performance:Latency (1 Gbps): 2.8 µs ¦ Latency (10 Gbps): 1.8 µs ¦ Latency (40 Gbps): 1.5 µs ¦ Throughput (64-byte packet size): up to 285.7 Mpps ¦ Routing/switching capacity: 480 Gbps ¦ Switching fabric speed: 508 Gbps
Capacity:IPv4 routing table entries: 10000 ¦ IPv6 forwarding table entries: 5000
Not in stock
Login for price
  • Specifications
  • Description
  • Accessories
General
Device Type:Switch - 16 ports - L3 - Managed - stackable
Enclosure Type:Rack-mountable 1U
Subtype:10 Gigabit Ethernet
Ports:16 x 10 Gigabit SFP+
Performance:Latency (1 Gbps): 2.8 µs ¦ Latency (10 Gbps): 1.8 µs ¦ Latency (40 Gbps): 1.5 µs ¦ Throughput (64-byte packet size): up to 285.7 Mpps ¦ Routing/switching capacity: 480 Gbps ¦ Switching fabric speed: 508 Gbps
Capacity:IPv4 routing table entries: 10000 ¦ IPv6 forwarding table entries: 5000
MAC Address Table Size:64K entries
Jumbo Frame Support:Yes
Routing Protocol:OSPF, BGP-4, RIP-1, RIP-2, BGP, VRRP, OSPFv2, IGMPv3, OSPFv3, static IPv4 routing, static IPv6 routing, RIPng, MLD, Bidirectional Forwarding Detection (BFD), CIDR
Remote Management Protocol:SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, CLI, XRMON, SSH 6
Encryption Algorithm:MD5, SSL, TLS
Authentication Method:RADIUS, TACACS+, Secure Shell v.2 (SSH2), Extensible Authentication Protocol (EAP)
Features:Flow control, DHCP support, BOOTP support, VLAN support, auto-uplink (auto MDI/MDI-X), Syslog support, IPv6 support, half duplex mode, full duplex mode, sFlow, VRRP support, MSTP support, QoS, PVST+, STP Root Guard, UDLD, LACP, dynamic ARP protection, DHCP protection, GVRP, Zero Touch Auto Provisioning, MVRP, Ingress Layer 2 MAC ACLs, CoS, MACsec support, DNS client, layer 4 prioritisation:, 13.5MB packet buffer
Compliant Standards:IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1v, IEEE 802.1AX
Processor:2
RAM:6 GB DDR3 SDRAM
Flash Memory:1 GB
Expansion / Connectivity
Interfaces:16 x 10Gbit LAN SFP+ ¦ 1 x serial (console) RJ-45 ¦ 1 x management RJ-45 ¦ 1 x RJ-45 ¦ 1 x Type B
Expansion Slots:1 (total) / 1 (free) x Stacking Module ¦ 2 (total) / 2 (free) x Expansion Slot
Power
Power Device:Internal power supply (not installed) - hot-plug
Max Supported Qty:2
Power Redundancy:Yes
Miscellaneous
Included Accessories:Fan tray
Rack Mounting Kit:Included
Compliant Standards:FCC Class A certified, CISPR 22 Class A, EN 60950, EN55022, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 60950, UL 60950, Laser Class 1, UL 60950-1, EN 60825, EN 61000-3-3:2008, CAN/CSA C22.2 No. 60950, VCCI Class A, EN55022:2010, IEC 60950-1:2005 Second Edition, EN 55024:2010, EN 62368-1 Second Edition, IEC 60825:2007, EN 60850-1:2007, IEC 60825-1:2007 Class 1, UL 62368-1 Second Edition, EN 61000-3-2:2006+A1:2009+A2:2009 Class A, CAN/CSA-C22.2 No. 60950-1, EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013
Dimensions & Weight
Width:44.25 cm
Depth:43.13 cm
Height:4.39 cm
Weight:6.02 kg
Manufacturer Warranty
Service & Support:Limited warranty - lifetime
Environmental Parameters
Min Operating Temperature:0 °C
Max Operating Temperature:45 °C
Humidity Range Operating:15 - 95% (non-condensing)
Min Storage Temperature:-40 °C
Max Storage Temperature:70 °C
Humidity Range Storage:15 - 90% (non-condensing)
vis mere
The Aruba 3810 Switch Series provides performance and resiliency for enterprises, SMBs, and branch office networks. With HPE Smart Rate multi-gigabit ports for high-speed 802.11ac devices, this advanced Layer 3 switch delivers a better application experience with low latency, virtualization with resilient stacking technology, and line rate 40GbE for plenty of back haul capacity. The Aruba 3810 is easy to deploy and manage with advanced security and network management tools like Aruba ClearPass Policy Manager, Aruba AirWave and cloud-based Aruba Central.
  • Performance and power for the mobile-first campus
  • Resiliency and high availability you can depend on
  • Trusted security with unmatched quality of service
  • Simplify with unified management
