Epson TM S1000 - document scanner - desktop - USB 2.0

SKU A41A266031
Product Description:Epson TM S1000 - document scanner - desktop - USB 2.0
Device Type:Document scanner - desktop
Interface Type:USB 2.0
Scanning Sensor Type:Contact Image Sensor (CIS)
Max Supported Document Size:120 x 235 mm
Input Type:Monochrome
Grayscale / Color Depth:8-bit (256 grey levels)
18-02-2025
  • Specifications
  • Description
General
Type:Document scanner - desktop
Interface Type:USB 2.0
Max Supported Document Size:120 x 235 mm
Enclosure Colour:Dark grey
Scanner
Input Type:Monochrome
Grayscale Depth:8-bit (256 grey levels)
Optical Resolution:200 dpi x 200 dpi
Automatic Duplexing:Yes
Scanning Sensor Type:Contact Image Sensor (CIS)
Scan Speed:60 ppm
Barcodes:E13-B, CMC-7, OCR-A, OCR-B
Media Handling
Document Feeder Type:Automatic
Document Storage Capacity:100 sheets
Expansion / Connectivity
Interfaces:USB 2.0 - Mini-B
Software / System Requirements
OS Required:Microsoft Windows XP Home Edition, Microsoft Windows 2000 Professional SP4, Microsoft Windows XP Professional SP2, Microsoft Windows Vista Business (32/64 bits), Microsoft Windows Vista Home Premium (32/64 bits), Microsoft Windows Vista Home Basic (32/64 bits), Microsoft Windows Vista Ultimate (32/64 bits)
System Requirements Details:Pentium 4 - 1.2 GHz - RAM 256 MB
Dimensions & Weight
Width:16 cm
Depth:35.5 cm
Height:17.6 cm
Weight:4 kg
vis mere
High reliability cheque and coupon scanner
Epson’s TM-S1000 cheque scanner is ideal for banks and corporations that want to capture cheques using back office capture (BOC), remote deposit capture (RDC) or a combination of the two. The Epson cheque scanner comes in both a 30 DPM and 60 DPM version and features RDMs MICR algorithms and imaging to provide one of the highest MICR accuracy of any desktop scanner on the market today. The TM-S1000 also features clear electronic endorsements, a double cheque detector that virtually eliminates double cheque feeding and a built-in franker that prints a static message on cheques to prevent double processing.
Flexibility to meet application requirements
The TM-S1000 comes with two pocket support as a standard feature. This gives you the flexibility to process and segregate different types of documents such as cheques and payment coupons. In addition, the 100 sheet document feeder allows high volume processing.
Easy to use and control
Whether you use TM-S1000 in the back office or at a busy teller station, the S1000 has been designed for easy maintenance. The cheque scanning process is simple and replacing the franker unit is quick and easy with no special training required. The Scanner also features advanced self-diagnostics which keep the operator informed of the scanner status and clear error messages.
Epson quality and reliability
With a MCBF of 2.47 million documents, the TM-S1000 has the reliability you need. As a world leading manufacturer of retail and office equipment, Epson offers high quality engineering with world class quality control and support.
  • High reliability cheque and coupon scanner
