Epson EB-805F - 3LCD projector - ultra short-throw - LAN - black

SKU V11H923640

Product Description:	Epson EB-805F - 3LCD projector - ultra short-throw - LAN - black
Device Type:	3LCD projector - 1080p
Colour:	Black
Built-in Devices:	Stereo speakers
Brightness (White):	5000 lumens
Brightness (Colour):	5000 lumens
Contrast Ratio:	2500000:1 (dynamic)

13-01-2025

Specifications
Description
Accessories

General
Device Type:	3LCD projector - 1080p
Built-in Devices:	Stereo speakers
Networking:	Ethernet
Enclosure Colour:	Black

Projector
Brightness (White):	5000 lumens
Brightness (Colour):	5000 lumens
Brightness (Reduced):	3500 lumens
Contrast Ratio:	2500000:1 (dynamic)
Image Size:	165.1 cm - 330 cm
Projection Distance:	0.4 m
Throw Ratio:	0.27 - 0.37:1
Digital Zoom Factor:	1.35x
Resolution:	Full HD - Full HD (1920 x 1080)
Native Aspect Ratio:	16:9
Colour Support:	1.07 billion colours
Max Sync Rate (V x H):	240 Hz
Bulb type:	Laser diode
Bulb life cycle:	Up to 20000 hour(s) - normal mode ¦ Up to 30000 hour(s) - economic mode
Features:	sRGB colour profile, freeze frame, Blackboard Mode, Edge blending, EPSON 3LCD technology, Split Screen, DICOM Simulation Mode, Direct Power On, Direct Power Off, Dynamic Mode, auto power on, Auto Calibration, Eco Mode, instant on/off, Presentation Mode, Cinema Mode

Lens
Type:	Ultra short-throw lens
Focus Type:	Manual
Lens Aperture:	F/1.5
Keystone Correction Direction:	Horizontal, vertical
Vertical Keystone Correction:	-3 / +3
Horizontal Keystone Correction:	-3 / +3

Video Input
Video Interfaces:	VGA, HDMI, composite video, HDBaseT
LAN and Wireless Image Transferring Protocols:	Wired LAN

Speakers
Type:	Integrated
Sound Output Mode:	Stereo
Output Power / Channel:	8 Watt
Speakers:	2 x right / left channel

Expansion / Connectivity
Interfaces:	2 x VGA input - 15 pin HD D-Sub (HD-15) ¦ 1 x HDMI output - 19 pin HDMI Type A ¦ 3 x HDMI input - 19 pin HDMI Type A ¦ 2 x USB 2.0 - 4 pin USB Type A ¦ 1 x HDBaseT - RJ-45 ¦ 3 x audio line-in - mini-phone stereo 3.5 mm ¦ 1 x audio line-out - mini-phone stereo 3.5 mm ¦ 1 x USB 2.0 - 4 pin USB Type B ¦ 1 x serial RS-232C ¦ 1 x network - RJ-45 ¦ 1 x VGA output - 15 pin HD D-Sub (HD-15)

Miscellaneous
Included Accessories:	Lens cover, cable cover, remote control, battery for remote control
Security Features:	Security lock slot (cable lock sold separately), password protection, padlock
Security Slot Type:	Kensington security slot

Power
Power Source:	AC
Voltage Required:	AC 120/230 V (50 - 60 Hz)
Power Consumption Operational:	366 Watt
Power Consumption Stand by:	0.5 Watt

Software / System Requirements
Software Included:	Epson iProjection, Epson Projector Content Manager

Dimensions & Weight
Width:	45.8 cm
Depth:	21 cm
Height:	37.5 cm
Weight:	9.4 kg

Manufacturer Warranty
Service & Support:	Limited warranty - 5 years / 12000 hours

Environmental Parameters
Min Operating Temperature:	-10 °C
Max Operating Temperature:	60 °C
Humidity Range Operating:	20 - 80%
Sound Emission:	36 dB
Sound Emission (Economic Mode):	27 dB

vis mere

This laser display solution brings informative signage to life and produces scalable projections of up to 130 inches. It brings a fresh dimension to signage with borderless images and projection onto ultra-wide surfaces, including glass and curved walls. The EB-805F features Full HD 1080p image quality and delivers powerful and informative displays for retail, hospitality and visitor attractions.

Ultra-short-throw signage projector: compact, unobtrusive design
Up to 130-inch display: Full HD resolution, 5000-lumen brightness and 3LCD technology
Fit and forget reliability: low-maintenance laser projector
Easy installation: 360-degree rotation with portrait projection support
Flexible playback: play content directly from a USB stick

The technical details come from 3rd party. edgemo is not responsible for any errors.
