Eaton G4 - power distribution unit - basic - 3.7 kW
SKU EVBAF116A
Product Description: | Eaton G4 - power distribution unit - basic - 3.7 kW |
Device Type: | Power distribution unit - rack-mountable |
Cord Length: | 3 m |
Weight: | 2.15 kg |
Input Wiring: | 1-phase |
Input Voltage: | AC 200-240 V |
Power Capacity: | 3.7 kW |
- Specifications
- Description
General | |
Device Type: | Power distribution unit - rack-mountable |
Cord Length: | 3 m |
Colour: | Black |
Power Device | |
Input Voltage: | AC 200-240 V |
Input Wiring: | 1-phase |
Frequency Required: | 50/60 Hz |
Input Connectors: | 1 x power IEC 60309 16A |
Power Output Connectors Details: | 12 x power IEC 60320 C13 ¦ 12 x power IEC 60320 C39 |
Max Electric Current: | 16 A |
Power Capacity: | 3.7 kW |
Miscellaneous | |
Cables Included: | Power cable - external - 3 m |
Rack Mounting Kit: | Included |
Features: | Aluminium housing, vertical orientation, P-lock power cord, colour-coded labels |
Compliant Standards: | CB, LVD, RoHS, WEEE, Packaging Directive, IEC 62368-1, IEC/EN 63000, EAC, UKCA, CM, UKR |
Manufacturer Warranty | |
Service & Support: | Limited warranty - 1 year |
Dimensions & Weight | |
Width: | 5.2 cm |
Depth: | 100 cm |
Height: | 5.3 cm |
Weight: | 2.15 kg |
The Eaton G4 power distribution unit offers a reliable and efficient solution for managing power distribution in data centers and IT environments. Designed with a focus on durability and space efficiency, it features an aluminum housing and a vertical orientation that fits seamlessly into any rack setup. This unit is not only easy to install, thanks to the included rack mounting kit, but also simplifies cable management with its color-coded labels and P-lock power cord feature. With a capacity to provide 3.7 kW of power across 24 output connectors, it ensures that a wide range of devices can be powered simultaneously. Furthermore, its compliance with numerous international standards, including CB, CM, EAC, and RoHS, makes the Eaton G4 a versatile choice for businesses operating in various regions. Whether you're looking to upgrade your current power distribution system or setting up a new one, the Eaton G4 offers a blend of performance, convenience, and compliance.
- 24 output connectors for extensive connectivity
- Compliant with multiple international standards for global use
- Includes rack mounting kit for easy installation
- Aluminum housing and vertical orientation for durable, space-saving design
- Color-coded labels and P-lock power cord feature for simplified cable management
