Printers & POSDIGITUS Professional DN-82160 - fibre media converter - 1GbE, 10Mb LAN, 100Mb LAN
SKU DN-82160
| Product Description: | DIGITUS Professional DN-82160 - fibre media converter - 1GbE, 10Mb LAN, 100Mb LAN |
| Device Type: | Fibre media converter - SC single-mode / RJ-45 |
| Form Factor: | External |
| Cabling Type: | 1000Base-LX, 1000Base-T, 100Base-TX, 10Base-T |
| Data Transfer Rate: | 1 Gbps |
| Optical Wave Length: | 1310 nm |
| Data Link Protocol: | 1GbE, 10Mb LAN, 100Mb LAN |
- Specifications
- Description
| General | |
| Device Type: | Fibre media converter |
| Form Factor: | External |
| Networking | |
| Connectivity Technology: | Wired |
| Cabling Type: | 1000Base-LX, 1000Base-T, 100Base-TX, 10Base-T |
| Data Link Protocol: | 1GbE, 10Mb LAN, 100Mb LAN |
| Data Transfer Rate: | 1 Gbps |
| Optical Wave Length: | 1310 nm |
| Max Transfer Distance: | 20 km |
| Status Indicators: | Status, link/activity |
| Features: | Auto-uplink (auto MDI/MDI-X), full duplex mode, half duplex mode |
| Compliant Standards: | IEEE 802.3af, IEEE 802.3at, IEEE 802.3, IEEE 802.3u, IEEE 802.3z |
| Expansion / Connectivity | |
| Interfaces: | 1 x Ethernet 1000Base-LX - SC single-mode female x 2 ¦ 1 x Ethernet 10Base-T/100Base-TX/1000Base-T (PoE) - RJ-45 female |
| Miscellaneous | |
| MTBF: | 500,000 hours |
| Power | |
| Power Over Ethernet (PoE): | PoE |
| Power Device: | External power adapter |
| Dimensions & Weight | |
| Width: | 9.5 cm |
| Depth: | 7 cm |
| Height: | 2.6 cm |
| Environmental Parameters | |
| Min Operating Temperature: | -20 °C |
| Max Operating Temperature: | 65 °C |
The media converters from DIGITUS are an optimal solution for the migration of copper and fiber optic signals. From now on, you can access the fiber optic technology and transmit fiber optic signals over several kilometers without having to replace your entire network cabling. The intuitive operation guarantees a quick and easy installation. Many years of experience and a diverse range of services make DIGITUS a reliable partner for your network technology.
- PoE power supplier, PSE
- Compatible with the IEEE802.3af and IEEE802.3at standards
- Compatible with IEEE802.3, IEEE802.3u and IEEE802.3z standards
- Automatic cable recognition - Auto MDI/MDI-X function
- Auto recognition of full and half duplex
- Converts wire-based network signals into fiber optic signals
- 10/100/1000Base-TX to 1000Base-LX
The technical details come from 3rd party. edgemo is not responsible for any errors.
