Printers & POSDell PowerEdge T560 - tower Xeon Silver 4410Y 2 GHz - 32 GB - SSD 480 GB
SKU CDKHV
| Product Description: | Dell PowerEdge T560 - tower Xeon Silver 4410Y 2 GHz - 32 GB - SSD 480 GB |
| Type: | Server - tower |
| Bundled Services: | 3 Years Basic Support with Next Business Day Onsite Service |
| Server Scalability: | 2-way |
| Processor: | 1 x Intel Xeon Silver 4410Y / 2 GHz (up to 3.9 GHz, (12-core) |
| Cache Memory: | 30 MB |
| Cache Per Processor: | 30 MB |
- Specifications
- Description
| General | |
| Type: | Server |
| Bundled Services: | 3 Years Basic Support with Next Business Day Onsite Service |
| Product Form Factor: | Tower |
| Embedded Security: | Trusted Platform Module (TPM 2.0) Security Chip |
| Server Scalability: | 2-way |
| Hot-Swap Bays Qty: | 8 |
| Colour: | Black |
| Processor / Chipset | |
| CPU: | Intel Xeon Silver 4410Y |
| Clock Speed: | 2 GHz |
| Max Turbo Speed: | 3.9 GHz |
| Number of Cores: | 12-core |
| CPU Qty: | 1 |
| Max CPU Qty: | 2 |
| CPU Upgradability: | Upgradable |
| Cache Memory | |
| Installed Size: | 30 MB |
| Cache Per Processor: | 30 MB |
| RAM | |
| Installed Size: | 32 GB (installed) / 1 TB (max) |
| Technology: | DDR5 SDRAM |
| Effective Memory Speed: | 2800 MHz |
| Rated Memory Speed: | 2800 MHz |
| Form Factor: | DIMM 288-pin |
| Slots: | 16 (Total) / 15 (empty) |
| Features: | Registered, dual rank |
| Configuration Features: | 1 x 32 GB |
| Hard Drive | |
| Type: | SSD - hot-swap - 2.5" |
| Capacity: | 1 x 480 GB |
| Interface Type: | SATA 6Gb/s |
| Features: | Read Intensive, 1 DWPD, advanced format 512 |
| Storage Controller | |
| Type: | 1 |
| Storage Controller Name: | PERC H355 Front |
| Optical Storage | |
| Type: | No optical drive |
| Monitor | |
| Monitor Type: | None. |
| Graphics Controller | |
| Graphics Processor: | Matrox G200 |
| Video Memory: | 16 MB |
| Video Interfaces: | VGA |
| Networking | |
| Interface (Bus) Type: | LAN-on-motherboard (LOM) |
| Ethernet Ports: | 2 x Gigabit Ethernet |
| Ethernet Controller: | Broadcom BCM5720 |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Controller: | Integrated Dell Remote Access Controller 9 Enterprise 16G |
| Expansion / Connectivity | |
| Bays: | 8 (total) / 7 (free) x hot-swap 3.5" |
| Interfaces: | 2 x LAN (Gigabit Ethernet) ¦ 2 x USB 2.0 (1 front, 1 rear) ¦ 2 x USB 3.0 (1 front, 1 rear) ¦ 1 x management - micro-USB (iDRAC Direct port) ¦ 1 x VGA (1 rear) ¦ 1 x management - RJ-45 (iDRAC dedicated port) |
| Miscellaneous | |
| Included Accessories: | Bezel |
| Pricing Type: | Build To Plan (BTP) |
| Manufacturer Selling Program: | Dell Smart Selection, Dell Smart Value |
| Power | |
| Device Type: | Power supply - hot-plug |
| Power Redundancy: | Yes |
| Power Redundancy Scheme: | 1+1 (with optional power supply) |
| Installed Qty: | 1 |
| Max Supported Qty: | 2 |
| Power Provided: | 700 Watt |
| 80 PLUS Certification: | 80 PLUS Titanium |
| Operating System / Software | |
| OS Provided: | No operating system |
| Dimensions & Weight | |
| Width: | 20 cm |
| Depth: | 71.31 cm |
A purpose-built office-friendly server, maximizing next-gen technologies with powerful GPU to achieve enterprise-level performance.
- Innovate where you never thought possible
- Office-friendly and hyper-capable
- Find your balance
- Made to scale
The technical details come from 3rd party. edgemo is not responsible for any errors.
