APC Basic Rack PDU AP6032A - power distribution unit

SKU A8974286
Product Description:APC Basic Rack PDU AP6032A - power distribution unit
Device Type:Power distribution unit - rack-mountable
Cord Length:3.65 m
Weight:2.78 kg
Input Voltage:AC 200-240 V
Output Voltage:AC 200-240 V + 6% / - 10%
Input Connectors:1 x power IEC 60309 32A
19-03-2025
Login for price
  • Specifications
  • Description
  • Accessories
General
Device Type:Power distribution unit - rack-mountable
Cord Length:3.65 m
Power Device
Input Voltage:AC 200-240 V
Input Voltage Margin:+ 6% / - 10%
Frequency Required:50/60 Hz
Input Connectors:1 x power IEC 60309 32A
Power Output Connectors Details:4 x power IEC 60320 C19 16A
Output Voltage:AC 200-240 V + 6% / - 10%
Max Electric Current:32 A
Miscellaneous
Cables Included:Power cable - integrated - 3.65 m
Features:Breaker protection, over current protection
Compliant Standards:UL, VDE, RoHS 2011/65/EU
Manufacturer Warranty
Service & Support:Limited warranty - 2 years
Environmental Parameters
Min Operating Temperature:0 °C
Max Operating Temperature:50 °C
Humidity Range Operating:5 - 95% (non-condensing)
Dimensions & Weight
Width:4.36 cm
Depth:9.29 cm
Height:43.81 cm
Weight:2.78 kg
Dimensions & Weight (Shipping)
Shipping Width:20.8 cm
Shipping Depth:18 cm
Shipping Height:47.8 cm
Shipping Weight:3.75 kg
vis mere
The APC by Schneider Electric Basic Rack Power Distribution Unit (PDU) distributes power to devices in the rack.
  • Integrated 3.65 m power cable for easy installation
  • Operates effectively in 5 - 95% humidity and temperatures from 0°C to 50°C
  • Compliant with RoHS, UL, and VDE standards for safety and reliability
  • Features breaker and overcurrent protection for enhanced safety
  • Supports AC 200-240 V with a + 6% / - 10% voltage margin for stable power supply




The technical details come from 3rd party. edgemo is not responsible for any errors.
