Printers & POSCisco Webex Room 55 - GPL - video conferencing kit - with Cisco Floor Stand Kit (CS-ROOM55-FSK), 2 x Cisco TelePresence Table Microphone 20 (CTS-MIC-TABL20+)
SKU CS-ROOM55-K9
| Product Description: | Cisco Webex Room 55 - GPL - video conferencing kit - with Cisco Floor Stand Kit (CS-ROOM55-FSK), 2 x Cisco TelePresence Table Microphone 20 (CTS-MIC-TABL20+) |
| Device Type: | Video conferencing kit |
| VoIP Protocols: | H.323, SIP, H.460 |
| Codec: | H.264, H.265, H.239, G.711, G.722, G.729, G.722.1, AAC-LD, Opus |
| Dimensions (WxDxH): | 1.25 m x 77.4 cm x 1.59 m |
| Weight: | 38 kg |
| Display: | 55" 3840 x 2160 |
- Specifications
- Description
| General | |
| Device Type: | Video conferencing kit |
| VoIP Protocols: | H.323, SIP, H.460 |
| Voice Codecs: | G.711, G.722, G.729, G.722.1, AAC-LD, Opus |
| Video Codecs: | H.264, H.265, H.239 |
| Quality of Service: | IEEE 802.1Q (VLAN), Differentiated Services (DiffServ), IEEE 802.1p |
| IP Address Assignment: | DHCP |
| Security: | IEEE 802.1X, H.235 v3 |
| Network Protocols: | HTTP, DNS, HTTPS, NTP |
| Width: | 1.25 m |
| Depth: | 77.4 cm |
| Height: | 1.59 m |
| Weight: | 38 kg |
| Bundled with: | Cisco Floor Stand Kit (CS-ROOM55-FSK), 2 x Cisco TelePresence Table Microphone 20 (CTS-MIC-TABL20+) |
| Display | |
| Diagonal Size: | 55" |
| Native Resolution: | 3840 x 2160 |
| Image Aspect Ratio: | 16:9 |
| Image Brightness: | 500 cd/m² |
| Image Contrast Ratio: | 1100:1 |
| Response Time: | 8 ms |
| Monitor Features: | HDCP |
| Modem | |
| Digital Signaling Protocol: | H.323, SIP, H.239, H.245, H.460.18, H.460.19, BFCP |
| Data Compression Protocol: | H.264, H.235 ver 3, H.239 |
| Features: | DTMF decoding |
| Video Input | |
| Type: | Digital video camera (colour) - external |
| Interface Type: | HDMI |
| Digital Video Capture Resolution: | 3840 x 2160, 1080p |
| Video Output | |
| Supported Display Graphics: | UHD (3840 x 2160) |
| Digital Video Standard: | High-Definition Multimedia Interface (HDMI) |
| Audio Input | |
| Type: | 6 microphones - integrated |
| Audio Output | |
| Type: | Speaker(s) |
| Frequency Response: | 70 - 20000 Hz |
| Input Device | |
| Type: | 10" touchscreen |
| Networking | |
| Connectivity Technology: | Wireless, wired |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, Bluetooth 4.0, IEEE 802.11ac |
| Network / Transport Protocol: | NTP, DHCP, DNS |
| Features: | Flow control, DiffServ support, IPv6 support, wall mountable, Quality of Service (QoS), SSH support, IPv4 support, 4K resolution support, automatic gain control (AGC), 802.1x authentication, URI Dialing |
| Compliant Standards: | IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x |
| Expansion / Connectivity | |
| Interfaces: | 2 x display / video - HDMI input - 19 pin HDMI Type A ¦ 1 x display / video - HDMI output - 19 pin HDMI Type A ¦ 1 x audio - output - mini-phone stereo 3.5 mm ¦ 2 x audio - input - mini-phone 3.5 mm 4-pole ¦ 2 x network - Ethernet 1000Base-T - RJ-45 ¦ 1 x USB 2.0 - 4 pin USB Type A ¦ 1 x USB 2.0 - 5 pin Micro-USB Type B |
| Miscellaneous | |
| Cables Included: | 1 x network cable - 5 m ¦ 1 x HDMI cable - 8 m ¦ 1 x network cable - 8 m |
| Mounting Kit: | Included |
| Compliant Standards: | AES, RoHS, WEEE, CEC, Directive 2002/96/EC, Directive 2011/65/EU, FCC CFR47 Part 15 B Class A, Directive 2014/35/EU, Directive 2014/30/EU, Directive 2014/53/EU |
| Power | |
| Power Device: | Power supply - external |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational: | 142 Watt |
| Software / System Requirements | |
| Software Included: | Cisco Spark Room |
| Manufacturer Warranty | |
| Service & Support: | Limited warranty - 90 days ¦ Limited warranty - advance parts replacement - 10 days |
| Environmental Parameters | |
| Min Operating Temperature: | 0 °C |
| Max Operating Temperature: | 40 °C |
| Humidity Range Operating: | 10 - 90% |
Bring intelligent views to every room. Discreet, integrated cameras provide ideal framing of participants and active speaker tracking. The systems wake when you walk into the room, and you can use your personal device to control them.
See your content in 4K resolution and share it over a wired or wireless connection. With support for dual screens, you can even share two content resources in local meetings.
See your content in 4K resolution and share it over a wired or wireless connection. With support for dual screens, you can even share two content resources in local meetings.
- Smart meetings
- Smart presentations
- Smart rooms
- Run in the cloud or on-premises
