Printers & POSCisco UCS B200 M3 Value SmartPlay Expansion Pack - blade - Xeon E5-2650 2 GHz - 128 GB - no HDD
SKU UCS-EZ-ENTV-B200M3
| Product Description: | Cisco UCS B200 M3 Value SmartPlay Expansion Pack - blade - Xeon E5-2650 2 GHz - 128 GB - no HDD |
| Type: | Server - blade |
| Server Scalability: | 2-way |
| Processor: | 2 x Intel Xeon E5-2650 / 2 GHz (2.8 GHz) (8-core) |
| Processor Socket: | LGA2011 Socket |
| Processor Main Features: | Hyper-Threading Technology, Intel Execute Disable Bit, Enhanced Intel SpeedStep Technology, Intel Virtualization Technology, Intel Turbo Boost Technology 2 |
| Cache Memory: | 40 MB L3 Cache |
- Specifications
- Description
| General | |
| Type: | Server |
| Product Form Factor: | Blade |
| Server Scalability: | 2-way |
| Hot-Swap Bays Qty: | 2 |
| Processor / Chipset | |
| CPU: | Intel Xeon E5-2650 |
| Clock Speed: | 2 GHz |
| Max Turbo Speed: | 2.8 GHz |
| Number of Cores: | 8-core |
| CPU Qty: | 2 |
| Max CPU Qty: | 2 |
| Processor Main Features: | Hyper-Threading Technology, Intel Execute Disable Bit, Enhanced Intel SpeedStep Technology, Intel Virtualization Technology, Intel Turbo Boost Technology 2 |
| CPU Socket: | LGA2011 Socket |
| Chipset Type: | Intel C600 |
| Cache Memory | |
| Installed Size: | L3 Cache - 40 MB |
| Cache Per Processor: | 20 MB |
| RAM | |
| Installed Size: | 128 GB / 384 GB (max) |
| Technology: | DDR3 SDRAM - ECC |
| Effective Memory Speed: | 1600 MHz |
| Rated Memory Speed: | 1600 MHz |
| Memory Specification Compliance: | PC3-12800 |
| Form Factor: | DIMM 240-pin |
| Slots: | 24 (Total) / 8 (empty) |
| Features: | Registered, dual rank |
| Configuration Features: | 16 x 8 GB |
| RAM Supported: | 384 GB registered - ECC ¦ 768 GB Load-Reduced - ECC |
| Hard Drive | |
| Type: | No HDD |
| Storage Controller | |
| Type: | RAID - integrated |
| Controller Interface Type: | SATA 6Gb/s / SAS 6Gb/s |
| Storage Controller Name: | LSISAS2004 |
| Channel Qty: | 4 |
| RAID Level: | RAID 0, RAID 1 |
| Optical Storage | |
| Type: | No optical drive |
| Monitor | |
| Monitor Type: | None. |
| Graphics Controller | |
| Type: | Integrated |
| Graphics Processor: | Matrox MGA G200e |
| Networking | |
| Type: | Plug-in module |
| Ethernet Ports: | 4 x 10 Gigabit Ethernet |
| Ethernet Controller: | Cisco UCS Virtual Interface Card 1240 |
| Data Link Protocol: | 10 Gigabit Ethernet, 10Gb Fibre Channel over Ethernet (FCoE) |
| Remote Management Controller: | Cisco Integrated Management Controller |
| Compliant Standards: | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ae, IEEE 802.1Qbb, IEEE 802.1Qaz |
| Expansion / Connectivity | |
| Bays: | 2 (total) / 2 (free) x hot-swap 2.5" |
| Slots: | 2 (total) / 0 (free) x CPU ¦ 24 (total) / 8 (free) x DIMM 240-pin ¦ 2 (total) / 1 (free) x expansion slot |
| Interfaces: | 1 x KVM |
| Miscellaneous | |
| Included Accessories: | 2 x CPU Heatsink |
| Compliant Standards: | CISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, VCCI Class A ITE, EN 61000-3-3, EN55024, EN55022 Class A, AS/NZS 60950-1, ICES-003 Class A, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60950-1, GB 4943, EN 300 386 |
| Manufacturer Warranty | |
| Service & Support: | Limited warranty - replacement - 3 years - on-site - response time: next business day |
| Dimensions & Weight | |
| Width: | 20.3 cm |
| Depth: | 62 cm |
| Height: | 5 cm |
| Weight: | 4.36 kg |
| Environmental Parameters | |
| Min Operating Temperature: | 10 °C |
| Max Operating Temperature: | 35 °C |
| Humidity Range Operating: | 5 - 93% (non-condensing) |
The Cisco Unified Computing System (Cisco UCS) combines Cisco UCS B-Series Blade Servers with networking and storage access in a single converged system that simplifies management and delivers greater cost efficiency and agility with increased visibility and control. This server increases compute density through more cores and cache balanced with more memory capacity and drives and with faster I/O. Together these server improvements and complementary Cisco UCS system advancements deliver the best combination of features and cost efficiency to support IT's diverse needs.
The Cisco UCS B200 M3 Blade Server delivers performance, versatility, and density without compromise. It addresses the broadest set of workloads, from IT and web infrastructure, through distributed database. Building on the success of the Cisco UCS B200 M2 Blade Server, the enterprise-class Cisco UCS B200 M3 Blade Server further extends the capabilities of the Cisco UCS portfolio in a half-width blade form factor. In addition, Cisco UCS has the architectural advantage of not having to power and cool excess switches in each blade chassis. With a larger power budget per blade server, Cisco can design uncompromised expandability and capabilities in its blade servers, as evidenced by the Cisco UCS B200 M3, with its leading memory slot and drive capacity.
The Cisco UCS B200 M3 Blade Server delivers performance, versatility, and density without compromise. It addresses the broadest set of workloads, from IT and web infrastructure, through distributed database. Building on the success of the Cisco UCS B200 M2 Blade Server, the enterprise-class Cisco UCS B200 M3 Blade Server further extends the capabilities of the Cisco UCS portfolio in a half-width blade form factor. In addition, Cisco UCS has the architectural advantage of not having to power and cool excess switches in each blade chassis. With a larger power budget per blade server, Cisco can design uncompromised expandability and capabilities in its blade servers, as evidenced by the Cisco UCS B200 M3, with its leading memory slot and drive capacity.
- Decreases total cost of ownership (TCO) by reducing the number of NICs, HBAs, switches, and cables needed
- Helps reduce the number of manual steps required to deploy servers in the data center, improving server policy consistency and coherency
- Allows servers and support infrastructure to be provisioned in minutes instead of days, shifting IT's focus from maintenance to strategic initiatives
- Reduces configuration errors significantly as blades are added or repurposed
- Enables service profile movement from blade to blade, rack server to blade, blade to rack server, or blade to blade in another chassis
- Through Cisco UCS Manager, provides extensive environmental monitoring for each blade
- Allows use of user thresholds to optimize environmental management of the blade
The technical details come from 3rd party. edgemo is not responsible for any errors.
