Cisco UCS B200 M3 Performance SmartPlay Expansion Pack - blade - Xeon E5-2680 2.7 GHz - 256 GB - no HDD

SKU UCS-EZ-PERF-B200M3
Product Description:Cisco UCS B200 M3 Performance SmartPlay Expansion Pack - blade - Xeon E5-2680 2.7 GHz - 256 GB - no HDD
Type:Server - blade
Server Scalability:2-way
Processor:2 x Intel Xeon E5-2680 / 2.7 GHz (3.5 GHz) (8-core)
Processor Socket:LGA2011 Socket
Processor Main Features:Hyper-Threading Technology, Intel Execute Disable Bit, Enhanced Intel SpeedStep Technology, Intel Virtualization Technology, Intel Turbo Boost Technology 2
Cache Memory:40 MB L3 Cache
Not in stock
Login for price
  • Specifications
  • Description
  • Accessories
General
Type:Server
Product Form Factor:Blade
Server Scalability:2-way
Hot-Swap Bays Qty:2
Processor / Chipset
CPU:Intel Xeon E5-2680
Clock Speed:2.7 GHz
Max Turbo Speed:3.5 GHz
Number of Cores:8-core
CPU Qty:2
Max CPU Qty:2
Processor Main Features:Hyper-Threading Technology, Intel Execute Disable Bit, Enhanced Intel SpeedStep Technology, Intel Virtualization Technology, Intel Turbo Boost Technology 2
CPU Socket:LGA2011 Socket
Chipset Type:Intel C600
Cache Memory
Installed Size:L3 Cache - 40 MB
Cache Per Processor:20 MB
RAM
Installed Size:256 GB / 384 GB (max)
Technology:DDR3 SDRAM - ECC
Effective Memory Speed:1600 MHz
Rated Memory Speed:1600 MHz
Memory Specification Compliance:PC3-12800
Form Factor:DIMM 240-pin
Slots:24 (Total) / 8 (empty)
Features:Registered, dual rank
Configuration Features:16 x 16 GB
RAM Supported:384 GB registered - ECC ¦ 768 GB Load-Reduced - ECC
Hard Drive
Type:No HDD
Storage Controller
Type:RAID - integrated
Controller Interface Type:SATA 6Gb/s / SAS 6Gb/s
Storage Controller Name:LSISAS2004
RAID Level:RAID 0, RAID 1
Optical Storage
Type:No optical drive
Monitor
Monitor Type:None.
Graphics Controller
Type:Integrated
Graphics Processor:Matrox MGA G200e
Networking
Type:Plug-in module
Ethernet Ports:4 x 10 Gigabit Ethernet
Ethernet Controller:Cisco UCS Virtual Interface Card 1240
Data Link Protocol:10 Gigabit Ethernet, 10Gb Fibre Channel over Ethernet (FCoE)
Remote Management Controller:Cisco Integrated Management Controller
Compliant Standards:IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ae, IEEE 802.1Qbb, IEEE 802.1Qaz
Expansion / Connectivity
Bays:2 (total) / 2 (free) x hot-swap 2.5"
Slots:2 (total) / 0 (free) x CPU ¦ 24 (total) / 8 (free) x DIMM 240-pin ¦ 2 (total) / 1 (free) x expansion slot
Interfaces:1 x KVM
Miscellaneous
Included Accessories:2 x CPU Heatsink
Compliant Standards:CISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, VCCI Class A ITE, EN 61000-3-3, EN55024, EN55022 Class A, AS/NZS 60950-1, ICES-003 Class A, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60950-1, GB 4943, EN 300 386
Manufacturer Warranty
Service & Support:Limited warranty - replacement - 3 years - on-site - response time: next business day
Dimensions & Weight
Width:20.3 cm
Depth:62 cm
Height:5 cm
Environmental Parameters
Min Operating Temperature:10 °C
Max Operating Temperature:35 °C
Humidity Range Operating:5 - 93% (non-condensing)
vis mere
The Cisco Unified Computing System (Cisco UCS) combines Cisco UCS B-Series Blade Servers with networking and storage access in a single converged system that simplifies management and delivers greater cost efficiency and agility with increased visibility and control. This server increases compute density through more cores and cache balanced with more memory capacity and drives and with faster I/O. Together these server improvements and complementary Cisco UCS system advancements deliver the best combination of features and cost efficiency to support IT's diverse needs.
The Cisco UCS B200 M3 Blade Server delivers performance, versatility, and density without compromise. It addresses the broadest set of workloads, from IT and web infrastructure, through distributed database. Building on the success of the Cisco UCS B200 M2 Blade Server, the enterprise-class Cisco UCS B200 M3 Blade Server further extends the capabilities of the Cisco UCS portfolio in a half-width blade form factor. In addition, Cisco UCS has the architectural advantage of not having to power and cool excess switches in each blade chassis. With a larger power budget per blade server, Cisco can design uncompromised expandability and capabilities in its blade servers, as evidenced by the Cisco UCS B200 M3, with its leading memory slot and drive capacity.
The bestselling blade, the B200 Performance package delivers outstanding performance for virtualization and databases. Great pricing makes this solution ready to go with four B200 blade servers and Includes the chassis and fabric interconnects, as well as, 40 Gbps I/O per blade.
  • Decreases total cost of ownership (TCO) by reducing the number of NICs, HBAs, switches, and cables needed
  • Helps reduce the number of manual steps required to deploy servers in the data center, improving server policy consistency and coherency
  • Allows servers and support infrastructure to be provisioned in minutes instead of days, shifting IT's focus from maintenance to strategic initiatives
  • Reduces configuration errors significantly as blades are added or repurposed
  • Enables service profile movement from blade to blade, rack server to blade, blade to rack server, or blade to blade in another chassis
  • Through Cisco UCS Manager, provides extensive environmental monitoring for each blade
  • Allows use of user thresholds to optimize environmental management of the blade




The technical details come from 3rd party. edgemo is not responsible for any errors.
