Printers & POSCisco DX80 - video conferencing kit
SKU CP-DX80-NR-K9=
| Product Description: | Cisco DX80 - video conferencing kit |
| Device Type: | Video conferencing kit |
| Dimensions (WxDxH): | 56.5 cm x 8.9 cm x 51.2 cm |
| Weight: | 7.1 kg |
| Display: | 23" 1920 x 1080 |
| Video Input: | Digital video camera |
| Audio Input: | Microphone |
- Specifications
- Description
| General | |
| Device Type: | Video conferencing kit |
| Width: | 56.5 cm |
| Depth: | 8.9 cm |
| Height: | 51.2 cm |
| Weight: | 7.1 kg |
| Built-in Devices: | Microphone, speaker, display, camera |
| Display | |
| Diagonal Size: | 23" |
| Native Resolution: | 1920 x 1080 |
| Image Aspect Ratio: | 16:9 |
| Image Brightness: | 215 cd/m² |
| Image Contrast Ratio: | 1000:1 |
| Response Time: | 5 ms |
| Monitor Features: | LED-backlit, 10-point multi-touch |
| Video Input | |
| Type: | Digital video camera (colour) - integrated |
| Digital Video Capture Resolution: | 1920 x 1080 |
| Audio Input | |
| Type: | Microphone - integrated |
| Audio Output | |
| Type: | Speaker(s) |
| Input Device | |
| Type: | Touch-screen |
| Networking | |
| Type: | Network adapter |
| Connectivity Technology: | Wired |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Network / Transport Protocol: | UDP/IP, DHCP, DNS, RTP, RTCP |
| Features: | VLAN support, Trivial File Transfer Protocol (TFTP) support, Quality of Service (QoS), Generic Attribute Registration Protocol (GARP) |
| Compliant Standards: | IEEE 802.3u, IEEE 802.3i, IEEE 802.3ab, IEEE 802.3q |
| Expansion / Connectivity | |
| Interfaces: | 2 x network - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 1 x display / video - HDMI input ¦ 1 x display / video - HDMI output ¦ 1 x USB 2.0 - 5 pin Micro-USB Type B ¦ 1 x USB 2.0 - 4 pin USB Type B ¦ 3 x USB 2.0 - 4 pin USB Type A |
| Miscellaneous | |
| Cables Included: | 1 x network cable - 2.9 m ¦ 1 x HDMI cable - 2 m ¦ 1 x power adapter |
| Compliant Standards: | EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class B, UL 60950-1, EN 60950-1, FCC CFR47 Part 15 B, CAN/CSA C22.2 No. 60950-1-07, Directive 2004/108/EC, Directive 2006/95/EC, Directive 2002/96/EC, Directive 2009/125/EC, Directive 2011/65/EU, EN 300 328, EN 301 489, EN 301 893 |
| Power | |
| Power Device: | Power supply - internal |
| Manufacturer Warranty | |
| Service & Support: | Limited warranty - advance parts replacement - 1 year |
| Environmental Parameters | |
| Min Operating Temperature: | 0 °C |
| Max Operating Temperature: | 40 °C |
| Humidity Range Operating: | 10 - 90% (non-condensing) |
Cisco DX80 is part of the DX Series desktop line within the Cisco portfolio of collaboration endpoints. It features an easy-to-use touchscreen with all commands onscreen. The DX80 offers everything you need to be productive in one sleek device that eliminates the need for an external monitor and an IP phone on the desk.
- Dedicated, always-on 1080p high-definition (HD) video communication system
- Extensive Cisco unified communications telephony feature compatibility
- 23-inch, 16:9 screen for an engaging experience during video calls and processing needs
- Multi-touch touchscreen for an elegant and powerful user interface
- High-quality audio system for speakerphone
- The intelligent audio feature eliminates background noise
- Cisco Extension Mobility supports multiple profiles, allowing hot-desking and shared workspaces
- Native Cisco AnyConnect VPN makes connecting to the workplace from the home office quick and easy
The technical details come from 3rd party. edgemo is not responsible for any errors.
