Cisco Catalyst 2960CX-8TC-L - switch - 8 ports - Managed - rack-mountable
SKU WS-C2960CX-8TC-L
Product Description: | Cisco Catalyst 2960CX-8TC-L - switch - 8 ports - Managed - rack-mountable |
Device Type: | Switch - 8 ports - Managed |
Enclosure Type: | Rack-mountable 1U |
Subtype: | Gigabit Ethernet |
Ports: | 8 x 10/100/1000 + 2 x SFP + 2 x 10/100/1000 (uplink) |
Performance: | Forwarding performance: 12 Gbps ¦ Forwarding performance (64-byte packet size): 17.9 Mpps |
Capacity: | Virtual interfaces (VLANs): 1023 |
- Specifications
- Description
General | |
Device Type: | Switch - 8 ports - Managed |
Enclosure Type: | Desktop, rack-mountable, DIN rail mountable, wall-mountable 1U |
Subtype: | Gigabit Ethernet |
Ports: | 8 x 10/100/1000 + 2 x SFP + 2 x 10/100/1000 (uplink) |
Performance: | Forwarding performance: 12 Gbps ¦ Forwarding performance (64-byte packet size): 17.9 Mpps |
Capacity: | Virtual interfaces (VLANs): 1023 |
Jumbo Frame Support: | 9018 bytes |
Routing Protocol: | RIP-1, RIP-2, static IP routing |
Remote Management Protocol: | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, CLI |
Authentication Method: | Kerberos, Secure Shell (SSH), RADIUS, TACACS+ |
Features: | BOOTP support, ARP support, VLAN support, Syslog support, DiffServ support, IPv6 support, Spanning Tree Protocol (STP) support, DHCP snooping, Port Aggregation Protocol (PAgP) support, Access Control List (ACL) support, Quality of Service (QoS), fanless, Shaped Round Robin (SRR), MAC Address Notification, Remote Switch Port Analyzer (RSPAN), Energy Efficient Ethernet, Multicast VLAN Registration (MVR), Class of Service (CoS), Weighted Tail Drop (WTD) |
Compliant Standards: | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ae, IEEE 802.1ab (LLDP), IEEE 802.3az |
RAM: | 512 MB |
Flash Memory: | 128 MB |
Status Indicators: | Port status, port transmission speed, port duplex mode, system, link/activity |
Expansion / Connectivity | |
Interfaces: | 8 x 1000Base-T RJ-45 ¦ 1 x console RJ-45 ¦ 1 x mini-USB Type B management ¦ 1 x USB Type A ¦ 2 x 1000Base-T RJ-45 uplink ¦ 2 x SFP uplink |
Power | |
Power Device: | Internal power supply |
Power Provided: | 300 Watt |
Voltage Required: | AC 120/230 V (50/60 Hz) |
Power Consumption Operational: | 16.7 Watt |
80 PLUS Certification: | 80 PLUS Silver |
Miscellaneous | |
MTBF: | 756,260 hours |
Compliant Standards: | GOST, CISPR 24, EN55022, EN55024, CISPR 22, CCC, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, ANATEL, GB 4943, KCC Class A, IEC 60825, KN22, KN24, VCCI V-3/2007.04 Class A, AS/NZS CISPR22:2004 Class A, CAN/CSA-C22.2 No. 60950-1 |
Software / System Requirements | |
Software Included: | Cisco IOS LAN Base |
Dimensions & Weight | |
Width: | 26.9 cm |
Depth: | 21.3 cm |
Height: | 4.44 cm |
Weight: | 1.72 kg |
Manufacturer Warranty | |
Service & Support: | Limited warranty - advance parts replacement - lifetime - response time: next business day ¦ Technical support - consulting - 90 days |
Environmental Parameters | |
Min Operating Temperature: | -5 °C |
Max Operating Temperature: | 45 °C |
Humidity Range Operating: | 5 - 95% (non-condensing) |
Min Storage Temperature: | -25 °C |
Max Storage Temperature: | 70 °C |
Humidity Range Storage: | 5 - 95% (non-condensing) |
The Cisco Catalyst 2960CX-8TC-L Network Switch is ideal for high-speed data connectivity and Wi-Fi backhaul in places where space is at a premium. Featuring a compact design and quiet, fanless operation, this managed switch can come out of the server room and be placed closer to users, meaning shorter cable runs and greater flexibility for your network deployment.
- Small form factor; fan-less design; silent operation
- Flexible mounting options
- 10-Gigabit SFP+ uplinks
