Brother ADS-4700W - document scanner - desktop - USB 3.0, LAN, Wi-Fi(n), USB 2.0 (Host)
SKU ADS4700WTF1
Product Description: | Brother ADS-4700W - document scanner - desktop - USB 3.0, LAN, Wi-Fi(n), USB 2.0 (Host) |
Device Type: | Document scanner - desktop |
Interface Type: | USB 3.0, LAN, Wi-Fi(n), USB 2.0 (Host) |
Scanning Sensor Type: | Dual CIS |
Light Source: | LED |
Additional Functions: | Scan to PC, scan to image, scan to network folder, scan to email, scan to FTP / SFTP, scan to SharePoint, scan to USB |
Max Supported Document Size: | 215.9 x 355.6 mm |
- Specifications
- Description
General | |
Type: | Document scanner - desktop |
Interface Type: | USB 3.0, LAN, Wi-Fi(n), USB 2.0 (Host) |
Additional Functions: | Scan to PC, scan to image, scan to network folder, scan to email, scan to FTP / SFTP, scan to SharePoint, scan to USB |
Max Supported Document Size: | 215.9 x 355.6 mm |
Scanner | |
Input Type: | Colour |
Grayscale Depth: | 8-bit (256 colours) |
Colour Depth: | 48-bit colour |
Colour Depth (External): | 24-bit (16.7 million colours) |
Optical Resolution: | 600 dpi x 600 dpi |
Interpolated Resolution: | 1200 dpi x 1200 dpi |
Automatic Duplexing: | Yes |
Scanning Sensor Type: | Dual CIS |
Bulb / Light Source Type: | LED |
Max Document Scan Speed B/W: | 40 ppm |
Max Document Scan Speed Colour: | 40 ppm |
Duty Cycle: | 6000 scans per day |
Scanner Speed Details: | 40 ppm - black & white - A4 ¦ 40 ppm - colour - A4 ¦ 80 ipm - duplex - black & white - A4 ¦ 80 ipm - duplex - colour - A4 |
Scanner Features: | Auto Deskew, auto image rotation, automatic page size detection, Automatic Separation, blank page skipping, Long Document Scanning, One-Touch button, Remove Background, 10.9 cm colour touch screen |
Compliant Standards: | SANE, TWAIN, WIA, ISIS |
Media Handling | |
Max Document Size: | 215.9 mm x 355.6 mm |
Supported Document Type: | Plain paper, business card, plastic card |
Supported Document Size Details: | ADF - up to 215.9 x 355.6 mm |
Document Feeder Type: | Automatic |
Document Storage Capacity: | 80 sheets |
Expansion / Connectivity | |
Interfaces Details: | USB 2.0 (Host) - Type A ¦ USB 3.0 ¦ LAN |
Miscellaneous | |
Cables Included: | 1 x USB cable |
Compliant Standards: | RoHS, GS, WHQL, WPA3 |
Power | |
Power Device: | Internal power supply |
Voltage Required: | AC 100-240 V (50/60 Hz) |
Power Consumption Operational (Standby): | 26 Watt |
Power Consumption Stand by: | 8.6 Watt |
Power Consumption Sleep: | 1.7 Watt |
Software / System Requirements | |
Software Included: | Kofax Power PDF Standard v3, BRAdmin Professional |
OS Required: | Apple macOS 10.14.x or later, Microsoft Windows 7 (32/64 bits) SP1, Windows 8.1 (32/64 bits), Windows 10 (32/64 bits), Microsoft Windows Server 2016, Microsoft Windows Server 2019, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2 |
Dimensions & Weight | |
Width: | 29.95 cm |
Depth: | 21.59 cm |
Height: | 19.05 cm |
Weight: | 2.75 kg |
Dimensions & Weight (Shipping) | |
Shipping Width: | 39.1 cm |
Shipping Depth: | 24.3 cm |
Shipping Height: | 32 cm |
Shipping Weight: | 3.46 kg |
Manufacturer Warranty | |
Service & Support: | Limited warranty - 2 years |
Environmental Parameters | |
Min Operating Temperature: | 5 °C |
Max Operating Temperature: | 35 °C |
Humidity Range Operating: | 20 - 80% |
Sound Emission: | 59 dB |
The Brother ADS-4700W document scanner is designed to enhance productivity and efficiency in any office setting. Featuring automatic duplexing, this scanner allows for fast, two-sided scanning without manual intervention, saving time and reducing workload. With a generous feeder capacity of 80 sheets, it can easily handle large scanning jobs, making it an ideal choice for busy environments. The scanner supports a wide range of document types, including business cards, plain paper, and plastic cards, offering the versatility needed to meet various scanning needs.
Connectivity is a breeze with USB 3.0 and Wi-Fi options, providing the flexibility to fit into any existing workflow seamlessly. The ADS-4700W boasts a high scan speed of up to 40 pages per minute in both black and white and color, ensuring that large volumes of documents can be processed quickly and efficiently. With compliance to ISIS, TWAIN, and WIA standards, this scanner ensures compatibility with a wide range of software applications, further enhancing its utility in professional settings.
Connectivity is a breeze with USB 3.0 and Wi-Fi options, providing the flexibility to fit into any existing workflow seamlessly. The ADS-4700W boasts a high scan speed of up to 40 pages per minute in both black and white and color, ensuring that large volumes of documents can be processed quickly and efficiently. With compliance to ISIS, TWAIN, and WIA standards, this scanner ensures compatibility with a wide range of software applications, further enhancing its utility in professional settings.
- Automatic duplexing for efficient two-sided scanning
- 80-sheet feeder capacity for handling large jobs
- USB 3.0 and Wi-Fi connectivity for flexible integration
- Fast 40 ppm scan speed in both color and black & white
