AXIS T8120 Midspan 15 W 1-port - PoE injector - 15 Watt

SKU 5026-222
Product Description:AXIS T8120 Midspan 15 W 1-port - PoE injector - 15 Watt
Device Type:PoE injector - external
Packaged Quantity:10 (specifications are for single item)
Weight:450 g
Input Voltage:AC 100-240 V
Output Voltage:48 V
Power Capacity:15 Watt
Not in stock
Login for price
  • Specifications
  • Description
  • Accessories
General
Packaged Quantity:10 (specifications are for single item)
Device Type:PoE injector - external
Power Device
Input Voltage:AC 100-240 V
Frequency Required:50 - 60 Hz
Power Output Connectors Details:1 x RJ-45
Output Voltage:48 V
Power Capacity:15 Watt
Expansion / Connectivity
Interfaces:1 x Gigabit LAN - RJ-45
Miscellaneous
Compliant Standards:UL, TUV, cUL, EN55022 Class B, FCC Part 15 B
Environmental Parameters
Min Operating Temperature:0 °C
Max Operating Temperature:40 °C
Humidity Range Operating:10 - 90% (non-condensing)
Dimensions & Weight
Width:6 cm
Depth:14.5 cm
Height:3.1 cm
Weight:450 g
Compatibility Information
Designed For:AXIS C1410, D3110, M1011 Network Camera, M1011-W Network Camera, M1013 Network Camera, M1014 Network Camera, M1031-W Network Camera, M1065-L, M3067-P, M3068-P, M4215-V, M4328-P, P1385-E, P1455-LE, P1455-LE-3 License Plate Verifier Kit, Q1656, Q1656-B, Q1951-E, W400 ¦ AXIS M42 Series M4215-LV, M4218-LV ¦ AXIS M55 Series M5526-E
vis mere
Power over Ethernet (PoE) offers an easy, fast and cost-effective solution for supplying power to network video products without the need to install power outlets and electrical cabling.
With the use of Axis PoE products, Axis network cameras and video encoders can receive both data and power over a single Ethernet cable. Network video products can thus be installed in areas where traditional power cabling and outlets are unavailable or difficult to install.
  • Reduced installation costs
  • IEEE 802.3af compliance
  • Easier and faster installations
  • No need for power outlets
  • Axis PoE midspans and PoE splitters




The technical details come from 3rd party. edgemo is not responsible for any errors.
