Printers & POSASUS TUF GAMING Z890-PRO WIFI - motherboard - ATX - LGA1851 Socket - Z890
SKU TUF GAMING Z890-PRO WIFI
| Product Description: | ASUS TUF GAMING Z890-PRO WIFI - motherboard - ATX - LGA1851 Socket - Z890 |
| Product Type: | Motherboard - ATX |
| Chipset Type: | Intel Z890 |
| Processor Socket: | 1 x LGA1851 Socket |
| Compatible Processors: | (supports Intel Core Ultra processors (Series 2)) |
| Max RAM Size: | 256 GB |
| RAM Supported: | 4 DIMM slots - DDR5, non-ECC, unbuffered |
- Specifications
- Description
| General | |
| Product Type: | Motherboard - ATX |
| Chipset Type: | Intel Z890 |
| Processor Socket: | LGA1851 Socket |
| Max Processors Qty: | 1 |
| Compatible Processors: | (supports Intel Core Ultra processors (Series 2)) |
| Supported RAM | |
| Max Size: | 256 GB |
| Technology: | DDR5 |
| Bus Clock: | 4533 MHz (O.C.) |
| Supported RAM Integrity Check: | Non-ECC |
| Registered or Buffered: | Unbuffered |
| Features: | Dual channel memory architecture, Intel Extreme Memory Profiles (XMP) |
| Audio | |
| Type: | HD Audio (8-channel) |
| Audio Codec: | Realtek ALC1220P |
| Compliant Standards: | High Definition Audio |
| LAN | |
| Network Interfaces: | 802.11a/b/g/n/ac/ax/be (Wi-Fi 7), Bluetooth 5.4, 2.5 Gigabit Ethernet |
| Expansion / Connectivity | |
| Expansion Slots: | 1 x CPU ¦ 4 x DIMM 288-pin ¦ 1 x PCIe 5.0 x16 ¦ 1 x PCIe 4.0 x16 (x4 mode) ¦ 1 x PCIe 4.0 x4 ¦ 2 x PCIe 4.0 x1 ¦ 2 x M.2 socket (2242/2260/2280 M.2 Key M slot) ¦ 1 x M.2 socket (2280 M.2 Key M slot) ¦ 1 x M.2 socket (2280/22110 M.2 Key M slot) |
| Storage Interfaces: | SATA-600 -connectors: 4 x 7pin Serial ATA ¦ PCIe 4.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5 ¦ PCIe 5.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5 ¦ PCIe 4.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 / RAID 5 ¦ SATA-600 / PCIe 4.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5 |
| Interfaces: | 1 x DisplayPort ¦ 1 x HDMI ¦ 2 x Thunderbolt 4/DisplayPort/USB4 ¦ 6 x USB 3.2 Gen 2 ¦ 2 x aerial ¦ 1 x LAN (2.5Gigabit Ethernet) ¦ 1 x audio line-out - mini-jack ¦ 1 x microphone - mini-jack ¦ 1 x audio line-in - mini-jack ¦ 1 x audio line-out (rear) - mini-jack ¦ 1 x audio line-out (center/subwoofer) - mini-jack ¦ 1 x SPDIF out |
| Internal Interfaces: | 1 x USB-C 3.2 Gen 2x2 - header ¦ 2 x USB 3.2 Gen 1 - header ¦ 4 x USB 2.0 - header ¦ 1 x serial - header ¦ 1 x audio - header ¦ 1 x Thunderbolt 4 - header |
| Power Connectors: | 24-pin main power connector, 2 x 8-pin ATX12V connectors |
| Features | |
| BIOS Type: | AMI |
| BIOS Features: | UEFI BIOS, ASUS EZ Flash, ASUS UEFI BIOS EZ Mode |
| Sleep / Wake Up: | Wake on LAN (WOL), wake on PME |
| Hardware Features: | Intel Turbo Boost Technology 2.0, Intel Turbo Boost Max Technology 3.0, ASUS Enhanced Memory Profile (AEMP) III, CUDIMM support, CrashFree BIOS 3, Preboot eXecution Environment (PXE), TUF LANGuard, BIOS FlashBack button, ASUS DIGI+ VRM, ASUS Overvoltage Protection, ASUS Q-Design, ASUS SafeSlot, ASUS Stainless Steel Back I/O, ASUS TUF Protection, ESD Guards, M.2 Q-Latch, M.2 Q-Release, M.2 Q-Slide, Q-Antenna, ASUS Aura Sync, ASUS EZ DIY, ASUS ProCool, ASUS SafeDIMM, BIOS FlashBack LED, CPU Socket lever protector, M.2 heatsink, M.2 heatsink backplate, pre-mounted I/O shield, Q-Dashboard, Q-DIMM, Q-LED, Q-Slot, VRM heatsink design, DIY Friendly Design, 16+1+2+1 Phase Power Design, NPU Boost, Q-Release Slim, AI Overclocking, AI Networking II, 8 Layer PCB |
| Miscellaneous | |
| Included Accessories: | ASUS Wi-Fi Q-antenna, M.2 Q-Slide, 2 x M.2 rubber package, M.2 screw package, TUF GAMING sticker, TUF GAMING removable nameplate |
| Cables Included: | 2 x SATA Express cable |
| Software Included: | Adobe Creative Cloud (free trial), Armoury Crate, ASUS AURA Creator, ASUS DriverHub, ASUS Fan Xpert 4, ASUS GlideX, ASUS TUF GAMING CPU-Z, DTS Audio Processing, Norton 360 for Gamers (60 days trial), TurboV Core, USB Wattage Watcher, WinRAR (40 days trial), ASUS AI Advisor |
| Compliant Standards: | DisplayPort 1.4 |
| Width: | 30.5 cm |
| Depth: | 24.4 cm |
The ASUS TUF GAMING Z890-PRO WIFI motherboard integrates advanced features tailored for gaming and demanding tasks. Equipped with a high definition audio codec, it supports immersive 8-channel sound for an enriched gaming experience. The motherboard also features multiple expansion slots, including four PCIe 4.0 and PCIe 5.0 configurations, ensuring flexibility for graphics and other components. With support for Intel Core Ultra processors and DDR5 memory technology, this motherboard meets the needs of gamers and creators alike.
In addition to performance capabilities, the TUF GAMING Z890-PRO WIFI incorporates robust hardware protections such as ESD Guards, TUF LANGuard, and ASUS Overvoltage Protection. Its networking options support multiple data link protocols including Wi-Fi 7 and Bluetooth 5.4, providing enhanced connectivity. Moreover, the DIY-friendly design features like BIOS FlashBack and Q-Release streamline the build process, offering peace of mind for enthusiasts looking for reliability and performance.
In addition to performance capabilities, the TUF GAMING Z890-PRO WIFI incorporates robust hardware protections such as ESD Guards, TUF LANGuard, and ASUS Overvoltage Protection. Its networking options support multiple data link protocols including Wi-Fi 7 and Bluetooth 5.4, providing enhanced connectivity. Moreover, the DIY-friendly design features like BIOS FlashBack and Q-Release streamline the build process, offering peace of mind for enthusiasts looking for reliability and performance.
- High definition audio with Realtek ALC1220P codec
- Supports DDR5 RAM with speeds up to 4533 MHz overclocked
- Multiple expansion slots including PCIe 5.0 for modern components
- Robust hardware protections for durability
- Comprehensive networking options with Wi-Fi 7 and Bluetooth 5.4
The technical details come from 3rd party. edgemo is not responsible for any errors.
