Printers & POSASUS TS700-E9-RS8 - tower no CPU - 0 GB - no HDD
SKU 90SF00K1-M00140
| Product Description: | ASUS TS700-E9-RS8 - tower no CPU - 0 GB - no HDD |
| Type: | Server - tower |
| Height (Rack Units): | 5U |
| Server Scalability: | 2-way |
| Processor: | No CPU |
| Processor Socket: | LGA3647-P0 Socket |
| RAM: | 0 GB (installed) / 1536 GB (max) - DDR4 SDRAM |
- Specifications
- Description
| General | |
| Type: | Server |
| Product Form Factor: | Tower - 5U |
| Server Scalability: | 2-way |
| Front Accessible Bays Qty: | 3 |
| Hot-Swap Bays Qty: | 8 |
| Processor / Chipset | |
| CPU: | No CPU |
| Max CPU Qty: | 2 |
| CPU Upgradability: | Upgradable |
| CPU Socket: | LGA3647-P0 Socket |
| Chipset Type: | Intel C621 |
| RAM | |
| Installed Size: | 0 GB (installed) / 1536 GB (max) |
| Technology: | DDR4 SDRAM |
| Form Factor: | DIMM 288-pin |
| Slots: | 12 (Total) / 12 (empty) |
| Features: | Registered, Load-Reduced DIMM (LRDIMM), 3DS Load-Reduced DIMM (LRDIMM), 6-channel memory architecture |
| RAM Supported: | 768 GB registered ¦ 768 GB Load-Reduced ¦ 1536 GB 3DS Load-Reduced |
| Hard Drive | |
| Type: | No HDD |
| Storage Controller | |
| Type: | 1 x RAID |
| Controller Interface Type: | SATA 6Gb/s |
| Channel Qty: | 8 |
| RAID Level: | RAID 0, RAID 1, RAID 5, RAID 10 |
| Storage Controller (2nd) | |
| Type: | 1 x SATA - SATA 6Gb/s |
| Channel Qty: | 2 |
| Optical Storage | |
| Type: | No optical drive |
| Monitor | |
| Monitor Type: | None. |
| Graphics Controller | |
| Graphics Processor: | ASPEED AST2500 |
| Video Memory: | 64 MB |
| Audio Output | |
| Compliant Standards: | High Definition Audio |
| Networking | |
| Ethernet Ports: | 2 x Gigabit Ethernet |
| Ethernet Controller: | 2 x Intel I210-AT |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Expansion / Connectivity | |
| Bays: | 8 (total) / 8 (free) x hot-swap 3.5" ¦ 3 (total) / 3 (free) x external 5.25" |
| Slots: | 2 (total) / 2 (free) x PCIe 3.0 x16 - full-length, full-height ¦ 2 (total) / 2 (free) x PCIe 3.0 x16 - full-length, full-height (dual x8 mode; single card: x16 mode) ¦ 2 (total) / 2 (free) x PCIe 3.0 x16 - full-length, full-height (x8 mode) ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, full-height ¦ 1 (total) / 1 (free) x M.2 Card |
| Interfaces: | 2 x LAN (Gigabit Ethernet) ¦ 4 x USB 2.0 (2 front, 2 rear) ¦ 1 x PS/2 keyboard / mouse ¦ 1 x TOSLINK ¦ 6 x USB 3.1 Gen 1 (2 front, 4 rear) ¦ 1 x headphones (1 in front) ¦ 2 x microphone (1 front, 1 rear) ¦ 1 x audio line-in ¦ 1 x audio line-out ¦ 1 x audio line-out (centre/subwoofer) ¦ 1 x audio line-out (rear) ¦ 1 x USB 3.1 Gen 2 ¦ 1 x USB-C 3.1 Gen 2 |
| Miscellaneous | |
| Compliant Standards: | FCC Class A certified, C-Tick, BSMI |
| Power | |
| Device Type: | Power supply |
| Power Redundancy: | Yes |
| Power Redundancy Scheme: | 1+1 |
| Installed Qty: | 2 |
| Max Supported Qty: | 2 |
| Power Provided: | 1300 Watt |
| Operating System / Software | |
| OS Provided: | No operating system |
| Dimensions & Weight | |
| Width: | 21.75 cm |
| Depth: | 54.5 cm |
| Height: | 45.5 cm |
| Weight: | 18.33 kg |
| Dimensions & Weight (Shipping) | |
| Shipping Weight: | 23.12 kg |
| Environmental Parameters | |
| Min Operating Temperature: | 10 °C |
| Max Operating Temperature: | 35 °C |
TS700-E9-RS8 features a flexible design that fits in both office and data-center environments. Its server rail kit enables easy integration into a data-center rack server, making TS700-E9-RS8 a perfect choice for system administrators who value easy upgradeability and deployment.
- Flexible design fits in the office or data center with server rail kit
- Redundant Platinum PSU support for high power efficiency
- Tool-less component replacement design for hassle-free maintenance
- High expandability and scalability
The technical details come from 3rd party. edgemo is not responsible for any errors.
