Printers & POSASUS RS500A-E11-RS12U - rack-mountable no CPU - 0 GB - no HDD
SKU 90SF01R1-M00220
| Product Description: | ASUS RS500A-E11-RS12U - rack-mountable no CPU - 0 GB - no HDD |
| Type: | Server - rack-mountable |
| Height (Rack Units): | 1U |
| Server Scalability: | 1-way |
| Processor: | No CPU |
| Processor Socket: | Socket SP3 |
| RAM: | 0 GB (installed) / 2048 GB (max) - DDR4 SDRAM |
- Specifications
- Description
| General | |
| Type: | Server |
| Product Form Factor: | Rack-mountable - 1U |
| Server Scalability: | 1-way |
| Hot-Swap Bays Qty: | 12 |
| Processor / Chipset | |
| CPU: | No CPU |
| Max CPU Qty: | 1 |
| CPU Upgradability: | Upgradable |
| CPU Socket: | Socket SP3 |
| RAM | |
| Installed Size: | 0 GB (installed) / 2048 GB (max) |
| Technology: | DDR4 SDRAM |
| Form Factor: | DIMM 288-pin |
| Slots: | 16 (Total) / 16 (empty) |
| Features: | Registered, Load-Reduced DIMM (LRDIMM), 8-channel memory architecture, 3DS Load-Reduced DIMM (LRDIMM) |
| RAM Supported: | 2048 GB registered |
| Hard Drive | |
| Type: | No HDD |
| Storage Controller | |
| Type: | 1 x NVMe |
| Controller Interface Type: | PCI Express (NVMe) |
| Channel Qty: | 12 |
| Optical Storage | |
| Type: | No optical drive |
| Monitor | |
| Monitor Type: | None. |
| Graphics Controller | |
| Graphics Processor: | ASPEED AST2600 |
| Video Memory: | 64 MB |
| Video Interfaces: | VGA |
| Networking | |
| Ethernet Ports: | 2 x Gigabit Ethernet |
| Ethernet Controller: | Intel I350-AM2 |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Features: | KVM over IP support |
| Expansion / Connectivity | |
| Bays: | 12 (total) / 12 (free) x hot-swap 2.5" |
| Slots: | 1 (total) / 1 (free) x PCIe 4.0 x16 - half-length, full-height ¦ 1 (total) / 1 (free) x PCIe 4.0 x16 - half-length, low-profile ¦ 1 (total) / 1 (free) x PCIe 4.0 x16 - half-length, low-profile (x8 mode) ¦ 2 (total) / 2 (free) x M.2 Card |
| Interfaces: | 2 x LAN (Gigabit Ethernet) ¦ 2 x USB 3.2 Gen 1 ¦ 1 x VGA ¦ 1 x management (NIC) - RJ-45 ¦ 1 x serial |
| Miscellaneous | |
| Included Accessories: | ASMB10-iKVM Remote Management Card |
| Compliant Standards: | FCC Class A certified, BSMI |
| Power | |
| Device Type: | Power supply |
| Installed Qty: | 2 |
| Max Supported Qty: | 2 |
| Voltage Required: | AC 100-127/200-240 V (50/60 Hz) |
| Power Provided: | 800 Watt |
| 80 PLUS Certification: | 80 PLUS Platinum |
| Operating System / Software | |
| OS Provided: | No operating system |
| Dimensions & Weight | |
| Width: | 44.9 cm |
| Depth: | 84.25 cm |
| Height: | 4.4 cm |
| Weight: | 17 kg |
| Dimensions & Weight (Shipping) | |
| Shipping Weight: | 22 kg |
| Environmental Parameters | |
| Min Operating Temperature: | 10 °C |
| Max Operating Temperature: | 35 °C |
- Up to 12 all-flash NVMe drives on front panel and four drives on middle panel to enable extensive storage and high-throughput performance
- Up to three PCIe 4.0 slots to enable higher bandwidth and improved data-transfer rates
- Onboard ASUS ASMB10-iKVM for out-of-band management with ASPEED AST2600 controller
- Integrated PFR FPGA as the platform Root-of-Trust solution for firmware resiliency
- Air cooling with heatsink achieves lower power-usage effectiveness (PUE) and optimized TCO for data centers
- New tool-less design for easy serviceability
The technical details come from 3rd party. edgemo is not responsible for any errors.
