Printers & POSASUS RS100-E11-PI2 - rack-mountable no CPU - 0 GB - no HDD
SKU 90SF02P1-M00110
| Product Description: | ASUS RS100-E11-PI2 - rack-mountable no CPU - 0 GB - no HDD |
| Type: | Server - rack-mountable |
| Height (Rack Units): | 1U |
| Server Scalability: | 1-way |
| Processor: | No CPU |
| Processor Socket: | LGA1200 Socket |
| RAM: | 0 GB (installed) / 128 GB (max) - DDR4 SDRAM |
- Specifications
- Description
| General | |
| Type: | Server |
| Product Form Factor: | Rack-mountable - 1U |
| Built-in Devices: | Led panel |
| Server Scalability: | 1-way |
| Internal Bays Qty: | 2 |
| Colour: | Silver |
| Processor / Chipset | |
| CPU: | No CPU |
| Max CPU Qty: | 1 |
| CPU Upgradability: | Upgradable |
| CPU Socket: | LGA1200 Socket |
| Chipset Type: | Intel C252 |
| RAM | |
| Installed Size: | 0 GB (installed) / 128 GB (max) |
| Technology: | DDR4 SDRAM |
| Form Factor: | DIMM 288-pin |
| Slots: | 4 (Total) / 4 (empty) |
| Features: | Unbuffered, dual channel memory architecture |
| Hard Drive | |
| Type: | No HDD |
| Storage Controller | |
| Type: | 2 x SATA |
| Controller Interface Type: | SATA 6Gb/s |
| RAID Level: | RAID 0, RAID 1, RAID 5, RAID 10 |
| Optical Storage | |
| Type: | No optical drive |
| Monitor | |
| Monitor Type: | None. |
| Graphics Controller | |
| Graphics Processor: | ASPEED AST2600 |
| Video Memory: | 64 GB |
| Video Interfaces: | VGA, HDMI |
| Networking | |
| Ethernet Ports: | 3 x Gigabit Ethernet |
| Ethernet Controller: | 2 x Intel I210-AT |
| Data Link Protocol: | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Expansion / Connectivity | |
| Bays: | 2 (total) / 2 (free) x internal 3.5" |
| Slots: | 1 (total) / 1 (free) x PCIe 4.0 x16 ¦ 1 (total) / 1 (free) x M.2 Card - 2280 |
| Interfaces: | 1 x serial (1 rear) ¦ 2 x LAN (Gigabit Ethernet) - RJ-45 (2 rear) ¦ 1 x management - RJ-45 (1 rear) ¦ 2 x USB 3.2 Gen 1 (2 front) ¦ 2 x USB 3.2 Gen 2 (2 rear) ¦ 2 x VGA (1 front, 1 rear) ¦ 1 x HDMI (1 rear) |
| Miscellaneous | |
| Compliant Standards: | FCC Class A certified, BSMI |
| Power | |
| Device Type: | Power supply |
| Power Provided: | 350 Watt |
| 80 PLUS Certification: | 80 PLUS Gold |
| Operating System / Software | |
| OS Provided: | No operating system |
| Dimensions & Weight | |
| Width: | 43 cm |
| Depth: | 38 cm |
| Height: | 4.4 cm |
| Weight: | 7.5 kg |
| Dimensions & Weight (Shipping) | |
| Shipping Weight: | 11.7 kg |
| Environmental Parameters | |
| Min Operating Temperature: | 10 °C |
| Max Operating Temperature: | 35 °C |
| Humidity Range Operating: | 20 - 90% |
- Powered by an advanced platform
- Powerful CPU and huge memory support
- Flexible storage expandability
- Dual Intel Gigabit Ethernet with teaming support
- Comprehensive I/O connectivity to meet different needs
- Complete server management with ASUS Control Center
The technical details come from 3rd party. edgemo is not responsible for any errors.
